High Sensitive Online Infrared Co/No Gas Analyzer with Factory Price
Nanjing AIYI Technologies Co., Ltd.- Brand：Aiyi
- Customized：Customized
- Portable：Non Portable
- Certification：CE, RoHS, ISO
- Gas：Co, CO2, C2h2, C2h4, CH4, C2h6, Biogas, So2, Nox
- Type：Ndir Infrared
Base Info
- Model NO.：AGA1010
- Gas Sensor：Imported Sensor From Europe
- Detection Principle：Ndir Infrared
- Gases Detected：Co, CO2, C2h2, C2h4, CH4, C2h6, Biogas, So2, Nox
- Measure Range：0-5%Vol, 0-25%Vol, 0-30%Vol
- Pretreatment System：Optional
- Output Signal：4-20mA , RS485
- Zero Drift：±2%F.S,7D
- Environment Temperature：-10ºC-50ºC
- Reaction Time：≤ 20s ( T90 )
- Measure Range Drift：±2%F.S,7D
- Transport Package：Carton
- Specification：650*500*265mm
- Trademark：AIYI
- Origin：Nanjing, China
- HS Code：8531100000
- Production Capacity：10000,Month
Description
NDIRSuitable gas CO: 0-3000ppm/1%15%30%100%VOL CO2: 0-2000ppm/1%/10%/30%/100%VOL
CH4: 0-3000ppm/5%/15%/100%VOL NO: 0-2000ppm
SO2: 0-1000/2000ppm
C2H6/C2H4/C2H2/C3H8
Customized Gas and Measure RangeZero Drift±2%F.S/7dSpan Drift±2%F.S/7dResponse Time≤20S(T90)Sample Gas Flow0.3-1.0L/min(Optimal Value: 0.4L/min)Sample Gas Pressure2-50kpaSignal Output4-20mA/RS485Operating Voltage220VACPretreatment SystemOptionalDimensions484mm*130mm*415mm560mm*330mm*330mmCabinet Size700mm*1800mm*710mm1100mm*1800mm*700mmCertificateCMCCMC/ Ex d II CT6 Gb
