IEC62271 Circuit Breaker Analyzer Switchgear Mechanical Properties Tester

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Speed Measurement：0m,S~20m,S
  • DC Power out：DC30V~250V,20A (Instantaneous)
  • Test Standard：IEC62271
  • Time Measurement Error：<1%Rdg+0.2ms
  • Time Measurement Range：6000ms, Resolution 0.1ms
  • Closing Resistance Value：100~10000ohm

Base Info

  • Model NO.：GDGK-303
  • Function：IEC62271 12 Channels
  • Weight：10kg
  • Transport Package：Standard Wooden Case
  • Specification：360mm*280mm*300mm
  • Trademark：GOLD
  • Origin：Chongqing
  • HS Code：9031809090
  • Production Capacity：50PCS,Month

Description

Time measurement range6000ms, resolution 0.1msTime measurement error<1%RDG+0.2msSpeed measurementRange 2m/s resolution 0.01m/s max error<0.1m/sRange 20m/s resolution 0.01m/s max error<0.2m/sTravel measurementRange 250.0mmresolution 1mmmax error 1mm
 DC Power outDC30V~250V/10A (instantaneous)
 Travel sensors configurationgrating and angle
 Test standardIEC62271LCD128*64Power supplyAC220V±10% 50Hz/60HzWorking ConditionTemperature: 0~50°C humidity: <85%
