Analysis Instrument

Non-Combustibility Test Apparatus En ISO 1182: 2020, Imo Ftpc Part 1, BS 476-4, En 13501

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service:Response in 12 Hours
  • Warranty:12 Months
  • Test Standard:En ISO 1182:2020,Imo Ftpc Part 1,BS 476-4,En 13501
  • Size:500mm X 500mm X 1500mm
  • Weight:50kg
  • Dimension of Heating Furnace:Φ95 mm × Φ75 mm × 150 mm

Base Info

  • Model NO.:NCF-TC
  • Operation:Controlled by PC
  • Diameter of Thermoucouple:Φ1.5 mm
  • Air Cover:Φ75 mm × 500 mm
  • Resistance Band:3 mm × 0.2 M Ni 80% Cr 20%
  • Temperature Control:750ºC±2ºC
  • Furnace Temperature:up to 900 ºC
  • Power Supply:220V, 50Hz, 1500W
  • Warrant:1 Year
  • Color:Grey
  • Software Language:English
  • Function:Non-Combustibility Test
  • Transport Package:Plywood Case
  • Specification:Stainless steel
  • Trademark:AI
  • Origin:China
  • HS Code:9031809090
  • Production Capacity:20 Sets,Month

Description

Basic Info.

Model NO. NCF-TC Operation Controlled by PC Diameter of Thermoucouple Φ1.5 mm Air Cover Φ75 mm × 500 mm Resistance Band 3 mm × 0.2 M Ni 80% Cr 20% Temperature Control 750ºC±2ºC Furnace Temperature up to 900 ºC Power Supply 220V, 50Hz, 1500W Warrant 1 Year Color Grey Software Language English Function Non-Combustibility Test Transport Package Plywood Case Specification Stainless steel Trademark AI Origin China HS Code 9031809090 Production Capacity 20 Sets/Month

Product Description

Introduction
This Building Material Non-Combustibility Apparatus meets the test standards of GB/T5464-2010 "Testing methods for non-combustibility of building materials", and ISO1182:2020 Reaction to fire tests for products - Non-combustibility test.


Feature

1, Applicable standards:ISO 1182:2020,BS 476-4 & 11,ASTM E 136;
2, Intelligent test system with Patent design;
3, Stainless steel burner, beautiful and easy to clean;
4, The heating furnace size: Φ95 mm × Φ75 mm × 150 mm;
5, 3 mm × 0.2 m Ni 80% Cr 20% resistance band;
6, Air cover: Φ75 mm × 500 mm;
7,Thermocouple:insulated nickel-chromium-nickel-aluminum Φ1.5 mm
8, The Building Material Non-Combustibility Apparatus is equipment with the power controller;
9, The temperature balanced time at 750ºC is about 35min~40min;
10, Thermometers range: 0 ~ 1000 ºC ± 5%;
11, The Building Material Non-Combustibility Apparatus is equipped with mirror to see the internal of the furnace.

Control system

1, High degree of automation, test procedure safe and reliable, easy to operate;
2, Use high-quality strip heater, furnace temperature was raised to 900 ºC;
3, PLC control system + SSR temperature control system extending the life of furnace:
4, PLC output signal to control the heating voltage 0-110VAC. Eliminate the influence of voltage fluctuation on temperature.
5, Temperature control: 750ºC±2ºC;Resolution:0.1ºC;
6, The sample is move up-down into the furnace automatically by motor.
7, Computer controlled with Labview based software
8, With an audible alarm and alarm display functions accidents.
9, Two furnace thermal couple for furnace control and temperature record, location show in below figure, compliance with ISO 1182-2020,
10, Thermocouple with copper cylinder for furnace temperature calibration.
11. Furnace temperature calibration and wall temperature calibration
12. Standard and new furnace heating mode.

13. Power:220V, 50Hz, 1500W ;
14. Weight:50kg;
15. Dimensions: 500mm x 500mm x 1500mm



Factory overview

Non-Combustibility Test Apparatus En ISO 1182: 2020, Imo Ftpc Part 1, BS 476-4, En 13501
Customer Feedback

Germany
Non-Combustibility Test Apparatus En ISO 1182: 2020, Imo Ftpc Part 1, BS 476-4, En 13501
USA
Non-Combustibility Test Apparatus En ISO 1182: 2020, Imo Ftpc Part 1, BS 476-4, En 13501
Transporation
Non-Combustibility Test Apparatus En ISO 1182: 2020, Imo Ftpc Part 1, BS 476-4, En 13501


FAQ

1.What's the delivery time?
About 2 months.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
