• Model NO.：AIC-1929
• Control System：PLC and Touch Screen
• Test Object：Plastics
• Test Control Range：Normal Temperature -500 ºC
• Diameter of Inner Tube：75 mm ±2 mm
• Lenght of Inner Tube：240 mm ± 20 mm
• Inner Diameter of Furnace Tube：100mm±5mm
• Length of Furnace Tube：230mm ± 20mm
• Flame Height：10mm-20mm
• Thermocouples：3 PCS
• Operation：Automatic
• Language：English
• Transport Package：Plywood Case
• Specification：Stainless steel
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：5 Sets,Month

Basic Info.

Model NO. AIC-1929 Control System PLC and Touch Screen Test Object Plastics Test Control Range Normal Temperature -500 ºC Diameter of Inner Tube 75 mm ±2 mm Lenght of Inner Tube 240 mm ± 20 mm Inner Diameter of Furnace Tube 100mm±5mm Length of Furnace Tube 230mm ± 20mm Flame Height 10mm-20mm Thermocouples 3 PCS Operation Automatic Language English Transport Package Plywood Case Specification Stainless steel Trademark AI Origin China HS Code 9031809090 Production Capacity 5 Sets/Month

Product Description

Introduction:

The ignition temperature test equipment is designed and manufactured in accordance with the technical indicators and requirements specified in ASTM D1929. Under the specified test conditions, the combustible gas separated from the material is ignited by an external flame and burned for a certain period of time, and then the lowest temperature of the material is measured.



Standards:

ASTM D1929 Test method for flammability of plastics-Determination of flash-ignition temperature and self-ignition temperature.



Features

1.The Ignition Temperature Test Equipment is integrated design, beautiful, easy to operate;

2.The heating furnace is made of stainless steel, beautiful and corrosion resistant;

3.The Ignition temperature test equipment consists of heating furnace, igniter and control system;

4.The inner diameter of furnace tube is 100mm ± 5mm, the length is 230mm ± 20mm,made of a ceramic that will withstand at least 750 ºC;

5.The inner tube diameter is 75 mm ±2 mm, length is 240 mm ± 20 mm, temperature resistance is not less than 750 ºC;

6.Size of stainless steel container: inner diameter 9mm, height 48mm.

7.Propane igniter inner diameter 1.8mm±0.3mm nozzle, flame height 10mm-20mm can be adjusted arbitrarily;

8.The copper ingot furnace can be constant at any temperature between (150-450) ºC

9.The Ignition Temperature Test Equipment is equipped with built-in fan to provide air source, and equipped with imported flowmeter to accurately control gas flow.

10.The thermal insulation layer is composed of thermal insulation mineral wool with a thickness of more than 60mm, and is wrapped in stainless steel;

11.Temperature control system: temperature control meter PID automatically controls the temperature of the heating furnace, the control temperature range: normal temperature -500 ºC, the heating furnace is equipped with 3 imported thermocouples to measure the temperature in the furnace and the temperature of the sample;

12.Sample container is made of stainless steel;

13.The accuracy of timer is 0.1s;

14. ASTM D1929 Ignition Temperature Test Equipment adopts automatic heating program;

15.PLC + touch screen control system; more intelligent test; test data automatic recording, automatic storage;

16.The software can automatically record the heating furnace curve, the sample temperature curve, and query the test data of sample;

17.Ambient temperature: room temperature~ 40 ºC;

18.Environmental humidity: ≤75%;

19.Precision of temperature control: +2 ºC, can be adjusted between 150 ºC and 450 ºC;

20.Display accuracy:±0.5 C;

21.Test Furnace dimension: 400*400*500mm;

22.Weight:50 Kg.

Factory overview

Customer Feedback

Germany

USA

Transporation

FAQ

1.What's the delivery time?
About 2 months.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
