• Model NO.：PLS-FSJ-150
• Performance：Automatic
• Power Supply：110V,220V
• Weight：0-50kg
• Certification：CE
• Application：Ultrasonic Mixer Homogenizer Sonicator
• Use：Separation, Dispersion, Homogenization
• Name：Ultrasonic Cell Disruptor Processor
• Usage：Laboratory, Biology Department
• Available Converter：100UL~100ml 1%~99%
• Transport Package：Carton or Other Required Package for
• Origin：Guangdong, China
• HS Code：8543709990
• Production Capacity：1000set,Month

Basic Info.

Model NO. PLS-FSJ-150 Performance Automatic Power Supply 110V/220V Weight 0-50kg Certification CE Application Ultrasonic Mixer Homogenizer Sonicator Use Separation, Dispersion, Homogenization Name Ultrasonic Cell Disruptor Processor Usage Laboratory, Biology Department Available Converter 100UL~100ml 1%~99% Transport Package Carton or Other Required Package for Origin Guangdong, China HS Code 8543709990 Production Capacity 1000set/Month

Product Description

Ultrasonic cell crusher is a multi-functional and multi-purpose instrument that uses strong ultrasound to produce cavitation effects in liquids and ultrasonically treat substances. It can be used to crush animal and plant tissues, cells, bacteria, and spores, and at the same time It can be used to emulsify, separate, disperse, homogenize, extract, degas, clean and accelerate chemical reactions, etc. This machine is widely used in teaching, scientific research and production in the fields of biochemistry, microbiology, medicinal chemistry, surface chemistry, physics, zoology, agronomy, medicine, pharmacy, etc.

With the development of the biological industry, the requirements for experiments using ultrasonic cell pulverizers have also increased, such as the measurement and control of sample temperature, low-temperature cooling of samples and the improvement of the intelligence of the whole machine, etc., all of which have put forward new requirements. .

The ultrasonic cell pulverizer uses the dispersion effect of ultrasonic waves in the liquid to cause the liquid to produce cavitation, thereby breaking the solid particles or cell tissues in the liquid. The ultrasonic cell pulverizer is composed of an ultrasonic generator and a transducer. . The ultrasonic generator transforms the mains electricity into 18-21KHz alternating electric energy to supply the transducer. The barium zirconate titanate piezoelectric vibrator is the heart of the transducer. It stretches and elastically deforms with the alternating voltage at a frequency of 18-21KHz, and the transducer vibrates longitudinally. The vibration wave generates a cavitation effect through the titanium alloy horn immersed in the biological solution, which excites the biological particles in the medium to vibrate violently.

 Features:
1. Precise and convenient digital displaying and controlling.
2. Digital display can show you the output power directly.
3. Output amplitude can be adjusted from 0% to 100%.
4. Two options available: Interval pulse modulate & constant output.
5. Pulse width and interval time can be separately set.
6. Its timer controlled and can switch off automatically when the set time is run off. You can turn it off when necessary.
7. Various kinds of converter are available.


Type	Power (w)	Output Amplitude	Available Converter
PLS-FSJ-100	100	1/8″3/16″1/4″	100ul~80ml    1%~99%
PLS-FSJ-150	150	1/8″3/16″1/4″	100ul~100ml  1%~99%
PLS-FSJ-250	250	1/8″3/16″1/4″	100ul~200ml   1%~99%
PLS-FSJ-500	500	1/8″3/16″1/4″1/2″	250ul~500ml   1%~99%
PLS-FSJ-800	800	1/8″3/16″1/4″1/2″3/4″	250ul~800ml   1%~99%
