• Frequency：50±1HZ
• Performance：Automation
• Weight：0-100Kg
• Power Source：AC220V±22V
• Customized：Customized
• Transport Package：Carton
• Specification：BS-ST-06
• Trademark：BIOSTELLAR
• Origin：China
• Production Capacity：1000000

Basic Info.

Frequency 50±1HZ Performance Automation Weight 0-100Kg Power Source AC220V±22V Customized Customized Transport Package Carton Specification BS-ST-06 Trademark BIOSTELLAR Origin China Production Capacity 1000000

Product Description

I. Product introduction
BS-st-06 soxhlet extractor, is the use of soxhlet extraction technology developed for laboratory determination of fat content equipment, with reasonable design, stable performance, high accuracy, operation effort, time saving, extraction method in line with (GB5512-85) standard. The instrument is ideal equipment for soxhlet extraction in food, oil, feed and soil industries.
II.product parameters
1. Product model: BS-ST-06
2. Number of samples extracted in each batch: 6;
3, fat tester extraction bottle volume: 250ml/ bottle or 500ml optional;
4. Extraction sample quantity: 0-5g/20g;
5, temperature control range: room temperature +5ºC~100ºC
6, power supply voltage: 220V±10V frequency 50Hz;
7, electric heating power: 800W;
8, controller: LIQUID crystal display
9, temperature control accuracy: ±0.3ºC
10. Heating time: about 10 minutes
11. Recovery system: automatic
12, solvent recovery: ≥80%
13, appearance size: 750*230*790mm;
14, weight: 26kg
III. Product features
1, heating extraction, solvent recovery and cooling three parts;
2, fat tester can operate according to the reagent boiling point and different environmental temperature and adjust the heating temperature;
3. The sample is repeatedly soaked and extracted in the extraction process, so as to achieve the purpose of rapid extraction;
4, can automatically recover solvent, greatly convenient for users to use, and save a lot of time;
5, fat tester extraction time can be adjusted, when the alarm.
