• Model NO.：BK-UV1200 BK-V1200
• Energy Resolution：≤8%
• Certification：CE, ISO
• Spectrometer Detector：SDD
• Stationary Phase：Liquid Solvent
• Mobile Phase：Liquid
• Chromatography Type：Liquid Chromatography
• Chromatographic Column Type：Convetional Analytical Column
• Chromatographic Column Length：10~20cm
• Chromatographic Column Diameter：1~2mm
• Optical System：Single Beam, Grating1200 Lines,mm
• Wavelength Range：200-1020nm
• Spectral Bandwidth：4nm
• Wavelength Accuracy：±1.5nm
• Wavelength Repeatability：≤0.5nm
• Transport Package：Carton Package
• Specification：560*430*320mm 12kg
• Trademark：BIOBASE
• Origin：China
• HS Code：9027300000
• Production Capacity：10000 Pieces,Year

Technical Parameters

Model

BK-UV1000

BK-V1000

BK-UV1200

BK-V1200

Optical System

Single Beam, Grating1200 lines/mm

Wavelength Range

200-1020nm

325-1000nm

200-1020nm

320-1020nm

Spectral Bandwidth

4nm

Wavelength Accuracy

±1.8nm

±1.5nm

Wavelength Repeatability

≤0.5nm

Photometric Accuracy

± 0.002A (0-0.5Abs), ± 0.004A (0.5-1.0Abs), ± 0.5% T (0-100% T)

Photometric Repeatability

0.001Abs (0-0.5Abs), 0.002Abs (0.5-1.0Abs),≤0.2% T (0-100% T)

Stray Light

≤0.1 % T @ 360nm; 220nm

≤0.2% T @ 360nm

Stability

± 0.001A / h @ 500nm

Noise

± 0.001A

Display

LCD

Photometric Mode

T, A, C, E

Photometric Range

0-200%T,-0.301-3.0A

Detector

Silicon Photodiode

Light Source

Lamp, Tungsten Lamp

Input

Membrane Keypad

Output

Parallel Print,USB1.0

Optional Accessories

Solid Sample Holder, Micro Cell Holder,10-100mm Cell Holder,PC software

Packing Size(W*D*H)(mm)

560*430*320

560*430*320

560*430*320

560*430*320

Gross Weight(kg)

12

11.5

12

11.5
