• Model NO.：JY-EC200
• Type：Electrochemical Gas Analyzer
• Test Principle：Fuel Cell
• Transport Package：Cartoon Box
• Specification：212*280*100(mm)
• Trademark：HT
• Origin：China
• HS Code：9027100090
• Production Capacity：200 Pieces, Month

Basic Info.

Model NO. JY-EC200 Type Electrochemical Gas Analyzer Test Principle Fuel Cell Transport Package Cartoon Box Specification 212*280*100(mm) Trademark HT Origin China HS Code 9027100090 Production Capacity 200 Pieces/ Month

Product Description

Technical Specifications:
   Measurement Principle: Fuel cell
   Display Mode: 128×64 dot matrix display LCD
   Measurement Range: 0~10/100/1000PPm O₂ (trace)
                                      0~1%/10%/25%/100% O₂ (normal)
   Measurement Accuracy: 0~1000PPm/1%/10%/25%/100%≤±1%FS
                                           0~100PPm≤±2%FS
                                           0~10PPm≤±5%FS
   Repeatability: ≤±1.0%FS
   Response Time: T₉₀≤60S (trace))
                              T₉₀≤40S (normal)
   Output Port: Charging port
   Environment Temperature: -10ºC~+50ºC
   Storage Environment Humidity: <90%RH, non-condensing
   Operation Environment Humidity: <100%RH, non-condensing
   Sample Gas Temperature: 0ºC~40ºC
   Sampling Mode: Gas in
   Sample Gas Flow: 400~600mL/min
   Gas Inlet Pressure: 5Kpa≤ relative pressure≤ 200Kpa (relief valve is recommended if the pressure >200Kpa)
   Gas Outlet Pressure: Free venting (under safe conditions)
   Background Gas: N₂ or other inert gas and reducing gas
   Explosion-Proof Level: Exib IIC T4
   Certificate Number: CNEx16.3613
   Gas Circuit Port: NPT 1/8 internal thread
   Battery Capacity: 4.2V, 4400mA
   Charging Power: AC220V±10% 50/60Hz
   Sensor Service Life: >36 months (under normal conditions of use)
   Instrument Weight: 3.6Kg
   Installation Method: Portable

Features:
   a.   The LCD display is clear and intuitive, and the operation of the instrument is easy and convenient;
   b.   The original imported fuel cell sensor has a high measurement accuracy, rapid response speed, long calibration cycle and strong anti-interference capability, etc.;
   c.   Automatic temperature compensation could eliminate the impact of environment temperature changes on the measured value;
   d.   The instrument allows multi-point fractional liner calibration, satisfying the need for an accurate measurement of oxygen content among the full range.
   e.   It is easy to operate and maintenance, and has a long service life;
   f.    It can operate more than 60 days after one full charge.

Application:
   It is applied in the oxygen analysis industries such as petrochemical industry, air separation, semiconductor industry protective gas detection, food production process gas detection, oxygen concentration measurement in hydrocarbon gas explosion-proof occasions, etc.

Order Notice (Please indicate following messages when placing orders)
   Measurement range
   Measured gas pressure
   Background gas composition
