• Model NO.：TPC-2100
• Resolution：0.1 Centigrade Degree
• Printer：Color Printer, Paper Size:44mm
• Ignition Mode：Electronic Ignition
• Self-Checking：Automatic Fault Checking
• Cooler：Strong Wind Cooling
• Power Consumption：Less Than 550va
• Power：AC220V Plus or Minus 10%
• Transport Package：Wooden Case
• Specification：480x260x300mm
• Trademark：TOP
• Origin：Chongqing, China
• HS Code：9027809900
• Production Capacity：200 Sets Per Month

Basic Info.

Model NO. TPC-2100 Resolution 0.1 Centigrade Degree Printer Color Printer, Paper Size:44mm Ignition Mode Electronic Ignition Self-Checking Automatic Fault Checking Cooler Strong Wind Cooling Power Consumption Less Than 550va Power AC220V Plus or Minus 10% Transport Package Wooden Case Specification 480x260x300mm Trademark TOP Origin Chongqing, China HS Code 9027809900 Production Capacity 200 Sets Per Month

Product Description

Fully Automatic Close Cup Oil Flash Point Analyzer (TPC-2100)

Application
Fully Automatic Flash Point Analyzer (closed cup) series TPC-2100 is designed as per requirements of GB261-83 and ISO2719-88, which adopts microcomputer technology, fully automatic, equipped with big screen LCD display and micro printer, with the function of self-checking, high precision test result, good repeatability, stable and reliable performance, easy to operate etc. It is good flash point analyzer (close cup) for petroleum, chemical, power Station, environment, railway, scientific research etc.

Main Features
1. Man-machine conversation LCD display
2. With the function of test date, test time
3. Automatic correct of the atmospheric pressure influence and correct values
4. Differential detection, self correction of error
5. Stirring, ignition, testing, fully automatic printing
6. with RS232, can connect with computer

Technical Parameters

Display	Big LCD display screen
Test method	Thermocouple differential detection
Test range	-20-300ºC
Resolution	0.1ºC
Repeatability	When flash point≤110ºC,allowed ±1ºC,when flash point>110ºC allowed ±2ºC
Printer	Color printer,paper size:44mm
Ignition mode	Electronic ignition
Self-checking	automatic fault checking
Cooler	Strong wind cooling
Power consumption	<550VA
Temperature	Atmospheric temperature: 10ºC-45ºC,humidity: 30-80%
Power	AC220V±10%
Dimension	480x260x300mm
Weight	18 kg

Main Oil Testers
1.Fully Automatic Karl Fischer Water Content Tester TP-2100
2.Kinematic Viscosity Tester VST-2000
3. Fully Automatic Oil Acidity Tester (6 cups) ACD-3000I
4. Fully Automatic Surface/Interface Tension Tester IT-800
5. Fully Automatic Open Cup Flash Point Tester TPO-3000
6.Fully Automatic Closed Cup Flash Point Tester TPC-3000
7.Cloud Point & Pour Point Tester PT-2000
8.Multi-functional Vibration Tester VBT-2000
9.Petroleum Products Density Tester DST-3000
10.Distillation Range Tester DIL-201
11.Liquid Phase Corrosion Tester TPS-05
12.Copper Corrosion Tester TP-113
13.Petroleum And Synthetic Liquid Anti-Emulsification Tester TP-122
14.Dew Point Tester DPME-P
15.Vehicle Gear Oil Channel Point Tester Model TP-0030
16.Anti-Corrosive Oil/Grease Salt Spray Corrosion Tester Model TP-0081
17. Mechanical Impurities Tester Model PC-511
18. Air Release Value Tester Model TP-0308
19.Distillate Fuel Oil Oxidation Stability Tester Model TP-175
20. Foam Characteristics Tester Model FC-892
21.Dark Petroleum Products Sulfur Content Tester Model TPC-120
22. Petroleum Products Aniline Point Tester Model TP-262A
23.Petroleum Products Ash Tester Model TP-508
24.Petroleum Products Chroma Tester Model TP-225
25. Automatic Petroleum Products Carbon Residue Tester (Micromethod) CS-0625
26.Spontaneous Ignition Point Tester FP-706
27.Fully Automatic Glassware Washing Machine TP504
28. Lube Oil/Grease Evaporation Loss Tester EL-7325
29. Crude Oil And Fuel Oil Sediment Tester TP-130
30. Wide Temperature Range Lubricating Grease Drop Point Tester TLS-22
31. Crude Oil And Petroleum Products Salt Content Tester SCA-068
32. Petroleum Products Saturated Vapor Pressure Tester(Reid Method) TP-8017
33.Petroleum Products Freezing Point Tester TP-2430
34. Oxygen Bomb Calorimeter TP-1B
35. Existent Gum Tester TP-509A
36.Octane and Hexadecane Value Tester TP-131
37.Automatic Gasoline Oxidation Stability Tester TP-148
38. Light Petroleum Products Sulfur Content Tester (Lamp-Kindled Method) TP-119
39. Resistant oil Chlorine Content Tester TP388
40. Distillate Fuel Mercaptan Sulfur Tester TP-624

About Us
Located at Chongqing city--a southwest electromechanical manufacturing center as well as national municipality, Chongqing TOP is a professional leading manufacturer and supplier of oil purifiers and various related testers. We consists of departments respectively for technological development, machinery manufacture, instrument manufacture, quality control etc. On basis of mature development and manufacture technology and highly qualified production management team, the products own high quality, easy operation, excellent performance and lone service life.

TOP Oil Purifiers are widespread in the fields of electric power, petrifaction, mineral, shipbuilding, steel construction, bridge, automobile and railway, playing a great role in reducing energy consumption for clients as well as environmental pollution. We provides you with reliable oil purifiers such as transformer oil purifier, turbine oil purification machine, hydraulic oil purifier, lubricating oil filtration machine, fuel oil restoration, oil and water separator, oil regeneration equipment, waste oil recycling equipment etc.

TOP Testers works on the development, production, market, technical and after-sale service for petrochemical analyzers, transformer substation electrical testing equipment and circuit detecting equipment. Main products are water content testers, surface/interfacial tension testers, flash point testers, kinematic viscosity testers, oil acidity testers, insulation oil dielectric strength testers, transformer characteristics testers, relay protection testers, high voltage testing equipment etc.

Service Commitment
1. Long-term warranty of 2 years.
2. Provide best necessary spare parts at low price (some for free).
3. Provide timely reply and technical support within 24 hours.
4. OEM is available for TOP Products.
5. Protect your sales area, ideas of design and all your private information.
