• Model NO.：MH-150Y
• Power Supply：220V
• Weight：0-50kg
• Certification：CE, RoHS
• Customized：Non-Customized
• Transport Package：Carton
• Specification：0.2-1200ml
• Trademark：none
• Origin：Shanghai

Basic Info.

Model NO. MH-150Y Power Supply 220V Weight 0-50kg Certification CE, RoHS Customized Non-Customized Transport Package Carton Specification 0.2-1200ml Trademark none Origin Shanghai

Product Description

Ultrasonic homogenizer MHY Series
onic homogenizers is a multi-function & multi-purpose instrument,
which use high strength ultrasonic to cause cavitations effect in liquid, for material ultrasonic processing.
Ultrasonic cell disruptor could crush a variety of animal & plant cells, viruses cells, also suitable for emulsification,
separate, homogenization, extraction, de-foaming, cleaning and speed up chemical reaction, etc.

Application: biological chemistry, microbiology, medicinal chemistry, surface chemistry, physics, zoology, etc.

Quality is our culture, let's learn MLH  series ultrasonic cell disruptors' advantages and your benefits:
1. LCD temperature control ultrasonic cell disruption system has beautiful appearance and reliable performance.
2. LCD large screen display, central computer centralized control, ultrasonic / interval / total time / power these could
be set by yourself, starting up amplitude transformer is optional, sample temperature display.
3. Automatic frequency tracking and fault automatic alarm,very convenient for your operation and guarantee your
research accuracy.


4. Ultrasonic cell disruption system use PWM to control switch power, power is continuously adjustable, could store
50 sets research parameters, all functions display in large screen.
5. Instrument protection system: Over-temperature protection, over-power protection, overtime protection. Make your
research be safe and longer ultrasonic cell disruptor service life.

Ultrasonic cell disruptor, technical specification of ultrasonic homogenizers:

Model	MH-150Y	MH-250Y	MH-650Y	MH-1000Y	MH-1200Y	MH-1800Y
Frequency (KHz)	20-25KHz	20-25KHz	20-25KHz	20-25KHz	19.5-20.5KHz	19.5-20.5KHz
Power (W)	1-150W  adjustable	5-250W  adjustable	10-650W  adjustable	10-1000W  adjustable	20-1200W  adjustable	50-1800W  adjustable
Horn (mm)	Φ6	Φ6	Φ6	Φ6 or Φ10	Φ20	Φ20 or Φ22
Optional Horn (mm)	Φ2,Φ3, Φ8	Φ2,Φ3, Φ8,Φ10	Φ2,Φ3, Φ8,Φ10, Φ12	Φ2,Φ3, Φ8,Φ10,Φ12,Φ15	Φ10,Φ15,Φ22,Φ25	Φ10,Φ15,Φ25,Φ28
Disruption Capacity (ml)	0.2-150	0.2-300	0.2-500	0.2-750	10-1000	20-1200
Store data	50 sets	50 sets	50 sets	50 sets	50 sets	50 sets
Temp alarm range	0-100 ºC	0-100 ºC	0-100 ºC	0-100 ºC	0-100 ºC	0-100 ºC
Instrument protection function	Over-temp. / over-power / overtime	Over-temp. / over-power / overtime	Over-temp. / over-power / overtime	Over-temp. / over-power / overtime	Over-temp. /  over-power / overtime	Over-temp. / over-power / overtime
Duty ratio	0.1-99.9%	0.1-99.9%	0.1-99.9%	0.1-99.9%	0.1-99.9%	0.1-99.9%
Display	LCD display	LCD display	LCD display	LCD display	LCD display	LCD display
