• Model NO.：Ndj-1f
• Spindle Speed：0.1~200 Rpm
• Transport Package：Carton Case
• Specification：SGS
• Trademark：SAMYON
• Origin：Cn
• HS Code：903180
• Production Capacity：100sets Per Month

Measurement range25 mPa·s~1×107 mPa·s ( If choosing the No.30 spindle, the measurement range can extend to 2×107 mPa·s)SpindleNo. 21, 27, 28, 29 total four types of spindles (the No.30 is optional)Spindle speed0.1~200 RPM, continuously speed regulation (With 12 grades of speed)Measurement error±2% (F·S), choosing the No.30 spindle, it will be ±3% (F·S)Temperature control range25 ºC~200 ºCTemperature control accuracy±0.1 ºCSample cylinder cubage20 mlPower supplyAC 220 V±10%, 50 HzAmbient temperature5 ºC~35 ºC (when the control temperature of the heater is close to the ambient temperature, turn on the air conditioner to allow the ambient temperature is approximately 5 ºC lower than the control temperature of the heater);Relative humidity≤80%
1. Measurement range: 25 mPa·s~1×107 mPa·s ( If choosing the No.30 spindle, the measurement range can extend to 2×107 mPa·s)
2. Spindle: No. 21, 27, 28, 29 total four types of spindles (the No.30 is optional)
3. Spindle speed: 0.1~200 RPM, continuously speed regulation (With 12 grades of speed)
4. Measurement error: ±2% (F·S), choosing the No.30 spindle, it will be ±3% (F·S)
5. Temperature control range: 25 ºC~200 ºC
6. Temperature control accuracy: ±0.1 ºC
7. Sample cylinder cubage: 20 ml
8. Power supply: AC 220 V±10%, 50 Hz
9. Ambient temperature: 5 ºC~35 ºC (when the control temperature of the heater is close to the ambient temperature, turn on the air conditioner to allow the ambient temperature is approximately 5 ºC lower than the control temperature of the heater);
10. Relative humidity: ≤80%
