• Model NO.：PTT-002
• HS Code：9101199000
• Production Capacity：200 Sets,Month

Basic Info.

Model NO. PTT-002 HS Code 9101199000 Production Capacity 200 Sets/Month

Product Description

Online Analyzing Oil Particle Counter (PTT-002)


Description
PTT-002 online pollution degree tester is an intelligent,  portable and  effective  analyzing  equipment. It could online test and display degree of pollution of oil from hydraulic and
lubricating system, so that maintenance staff could take preventive measures in early period,
avoiding abrasion and damage upon hydraulic components from containment. In this way, it
not only help you minimize maintenance expense, but also help decrease the shutdown time
of equipment. Series PTT-002 could also help  improve security  of system and  extend the  performance time of your equipment.
Application Area
PTT-002 adopts  OLED display screen and  displays the degree  of pollution of  oil in  digit.  It could test degree of pollution in mineral oils or phosphate synthetic oils, such as hydraulic
oil, lubricant oil, transformer oil(insulation oil), turbine oil,  gear oil,engine  oil and so on.  Currently, PTT-002 is widely used in  the fields of Aerospace,  Electricity, Petroleum,  Chemical Industry, Transportation, Harbour, Metallurgy, Machinery, Automobile Manufacturing etc.



Technical Parameters
Weight:538 g
Dimension:63mm×88mm×45 mm
Oil Temperature:-20ºC~80ºC
Storage Temperature:-40ºC~85ºC
Humidity:Operation under 20%~85%RH; Storage under 98%RH
Particulate Size:2µm,5µm,15µm,25 µm or 4µm(c),6µm(c),14µm(c),21 µm(c)
Connecting Screw Thread:M10×1mm
Standards of Pollution Degree:
ISO 4406 01~29
NAS 1638 00~12
PPM
Online Oil Flow Rate:50mL/min ~300 mL/min
Power Supply:DC 9V ~ 18V  (Power Supply Ripple Wave<30mVp-p)
Precision of Repeatability:±0.5 ISO Grade
