• Model NO.：SC80
• Specification：SGS
• Trademark：SADT
• Origin：China
• HS Code：9031809090
• Production Capacity：50 Piece,Pieces , Week

Basic Info.

Model NO. SC80 Specification SGS Trademark SADT Origin China HS Code 9031809090 Production Capacity 50 Piece/Pieces / Week

Product Description

Portable Color Difference Meter SC80

Introduction
SC80 precise color reader(color meter, colorimeter) is mainly applied to plastic, painting, design, plating, costume, printing and dyeing industries. SC80 coloimeter can do the color analysis and color controlling. Compared with other color meter, it has many advantages:

Key Features
The 2.4" colorful screen and portable design make you feel comfortable.
3 kinds of light sources for your selection, SCI and SCE mode switch and metamerism analysis satisfy your test needs in different working status.
Tolerance setting, auto-judge color difference values and color deviation make you judge the color easily even you don't have any professional knowledge in color.

Using professional color analysis software you can do the color data analysis and color difference diagrammatic outputting.
Via optional mini printer the color data can be printed out on site.
Similar model: TCR200ModelSC80 ( color meter, colorimeter)AccuracyLighting/Inspecting systemLight sourceInspection angleInspection conditionsRectificationStorageDisplayLanguageAperture (mm)Power supplyNet weight (g)Dimension (mm)


Specifications

Model	SC80
Accuracy	Standard deviation within ΔE*ab*, 0.08 (average value of 30 times @ the standard white tabula)
Measuring range	L*: 1-100
Illuminating system	8/d (8o diffuse illumination), specular component included (SCI)
Light source	LED
Inspection angle	10° angle of view in CIE
Measuring conditions	CIE 10° standard observer; CIE D65 light source
Measuring time	about 0.5 seconds
Rectification	White board rectification/Black board rectification
Storage	100 samples and 100 data groups for each sample
Display	Colorimetric values: L*a*b*, L*c*h*, ΔE*ab, XYZ, relative RGB values Color difference values: Δ(L*a*b), Δ(L*C*h) Whiteness values: hunter whiteness, ganz whiteness Yellowness value: YI
Communication inter face	USB2.0, printer(optional)
Aperture (mm)	Ø8
Power supply	4 pcs of AA alkaline batteries or nickel batteries special adaptor (DC, 5V)
Weight (g)	550g
Dimension (mm)	77x86x210
