High Quality GDSF-311WP SF6 Dew Point and Purity Comprehensive Tester

HV Hipot Electric Co., Ltd.
  • Brand：HV Hipot
  • Customized：Customized
  • Portable：Portable
  • Gas：Sf6 etc.
  • Type：Resistive and Capacitive measurement principle
  • Ambient environment temperature：-20ºC~-+60ºC

Base Info

  • Model NO.：GDSF-311WP
  • Measurement range：dew point -80ºC~+20ºC(support ppmv)
  • Resolution：0.01ºC
  • Dimension：395*295*155mm
  • Weight：about 2kg.
  • Transport Package：Standard Export Wooden Box
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan, China
  • HS Code：9030899090
  • Production Capacity：5000set,Year

Description

SF6 PurityMeasurement methodInfrared measurement principleMeasuring range0 ~ 100% SF6.,
Response time [90%] 60sMeasurement error better than ± 0.5%.FSRepeatability error ± 0.5%Resolution0.01%Display unit %Gas flow rate0~1000mL import digital flowmeterSample gas pressure ≤1MPaEnvironment humidity90%RHMeasurement value influenceNo effect of pressure and flowPower supply220VAC±10%, 50Hz, AC/DC use, over-charge protection, continuous working is more than 8hours.Dimension395*295*155mmWeightabout 2kg.
