Online Water Multi-Parameter Analyzer
Shanghai Boqu Instrument Co., Ltd.- After-sales Service：Support
- Warranty：1year
- Model：Dcsg-2099
- Item：Multi-Parameter
- Power Supply：DC220V
- Communication Interface：RS485 Modbus RTU
Base Info
- Model NO.：DCSG-2099
- Transport Package：PP Bag, Carton
- Specification：CE, SGS, ISO
- Trademark：Boqu
- Origin：Shanghai
- HS Code：9027809900
- Production Capacity：1000PCS,Year
Description
1. Display: LCD display, menu
2. Conductivity : Electrode constant (1 ~ 3000) μS / cm, 0 ~ 99.9 °C
0.01 ~ 30μS/cm; ( electrode constant K = 0.01 )
0.1 ~ 300μS/cm; ( electrode constant K = 0.1 )
1.0 ~ 3000μS/cm; ( electrode constant K = 1.0 )
10 ~ 30000μS/cm; ( electrode constant K = 10.0 )
3. Conductivity accuracy : ± 0.5% FS, ± 0.3 °C
4. pH measuring range : (0.00 ~ 14.00) pH;
Electronic unit basic error : ± 0.02pH
5. The basic error of the instrument : ± 0.05pH
6. The temperature range : 0 ~ 99.9 °C; electronic unit basic error : 0.3 °C
7. The basic instrument error : 0.5 °C (0.0 °C ≤ T ≤ 60.0 °C); another range 1.0 °C
8. The whole basic error : ug / L: ± 1.0% FS; mg / L: ± 0.5% FS; Temperature : ± 0.5 °C
9.The electronic unit basic error : ± 1.0% (FS); Instrument basic error : ± 2.0% (FS)
10. Measuring range: 0~10NTU,0~20NTU, 0~100NTU, 0~500NTU, 0~1000NTU
0~2000NTU, 0~4000NTU(specified when ordering)
11. Resolution:0.001NTU,0.01NTU,0.1NTU,1NTU
12. Each channel Independently: Each channel data measure simultaneously
13.Conductivity, temperature, Dissolved oxygen, pH, Turbidity and Chlorine value in the screen display, switch to display the other data.
14. Current isolated output: each parameter independently 4 ~ 20mA ( load <750Ω)
15. Power : AC220V ± 22V, 50Hz ± 1Hz, can be equipped with DC24V
16. RS485 communication interface ( optional ) ( ) with "√" indicating output
17. Protection: IP65
18. The working conditions : ambient temperature 0 ~ 60 °C, relative humidity ≤ 90 %
19. The entire instrument Weight : 4.0 kg
Packing & Delivery
Company Show
Abroad Exhibition
Customer Show
Application
Certification
FAQ1. Who are we?
BOQU instrument focus on R&D and production of Water Quality analyzer&sensor since 2007. Our mission is To be brightest eye for water quality monitoring on earth.★ Employees: 200+ people
★ Annual growth rate: 35%
★ R&D experiences: 20+ years
★ Technical patents: 50+
★ Annual production quantities: 150,000pcs
★ Cooperation companies: Boehringer Ingelheim, CM, Roche
★ Main Industries: Power plant, Water treatment plant, Drinking water, Pharmaceutical, Fish farming, Swimming pool.
2. How can we guarantee quality?
1) 100% OQC for all of products before shipping
Testing pictures and videos to be provided before shipping
3. What's our main business?
Whole solution for water quality instruments. Including analyzers and sensors for pH, COD, BOD,
conductivity, Dissolved Oxygen, Turbidity, TSS, Residual chlorine, Ammonia, Nitrate, Hardness and etc..
4. Why choose us instead of other suppliers?
1) Manufacturer was established since 2007, top supplier of water quality instrument.
One stop solution provider for water quality monitoring, thousands of projects reference.
24 hours after-sales service team, products training on time.
20+ years R&D experience, support OEM & ODM service.
50+ Patents for water quality analyzer and sensor
5. What service can we provide?
Incoterms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU,
Express Delivery, DAF, DES;
Payment Currency: USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY,CHF;
Payment method: T/T, MoneyGram, Credit Card, PayPal,Western Union, Cash, Escrow;
Language: English, Chinese, Spanish, Korean
