Multi-Functional Switchgear Sf6 Gas Analyser/Moisture Analyser/Dew Point Tester/Purity Tester Sf6 Decomposition Products Measuring Equipment
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Brand：Ephipot
- Customized：Customized
- Portable：Portable
- Certification：CE
Base Info
- Model NO.：EPFZ-III
- Gas：Sf6
- Type：Electrochemical Gas Analyzer
- Dew Point Measuring Range：-80~+20
- Purity Measuring Range：0-100%
- Decomposition Measuring Range：H2s:1-200ppm So2:1-100ppm Hf:0-10ppm Co: 0-1000
- Measuring Duration：15s
- Compact Design：Easy Handling and Transportation
- Working Supply：Both AC,DC, Built-in Batteries
- Communication：USB
- Key Words：Switchgear Gas Tester
- Weight：About 5kg
- Keyword：Sf6 Gas Tester
- with Only One Measurement：Sf6 Concentration (%) Moisture Concentration So2
- Option1：Hf Concentration (Ppmv)
- Option2：Co Concentration (Ppmv)
- Option3：H2s Concentration (Ppmv)
- User Language：English
- Transport Package：Plywood Case
- Trademark：EP Hipot
- Origin：Wuhan, China
- HS Code：903033200
- Production Capacity：2000,Year
Description
Measurement accuracyDew point:±0.5ºC(If below 0ºC,sensor displays frost point) SF6 purity:±0.1%,irrelevant of flow Inlet pressure ≤1.0Mpa Operation temperature -30~+50ºC Environment temperature ≤90%RH Charging voltage 220VAC±10% 50Hz Using time no less than 8 hours of continuous work Storage capacity 60 Size 360 × 350 × 160(mm) Weight 4.8 kg Operation method Touch input
More details on SF6 Gas Analyser please contact EP Hipot Electric, we have professional tech team to design correctly designed products and systems.
