Automatic Sf6 Gas Analyser Gas Dew Point Moisture Purity So2 Sof2 H2s Co H2 Measuring Machine
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Brand：Ep Hipot
- Customized：Customized
- Portable：Portable
- Certification：CE, Third Party Calibration IEC Laboratory
Base Info
- Model NO.：EPFZ-301
- Gas：Sf6 Gas
- Type：Electrochemical Gas Analyzer
- Epfz-301：Dew Point,Purity,Decomposition Products
- Sf6 Decomposition Products：H2s, So2, Sof2, Co, Hf Can Be Customized
- Measurement Accuracy：0.1
- Communication：RS232 or USB
- Operation Method：Touch Screen
- Weight：5.5 Kg
- Printing：Micro Printer
- Humidity：Dew Point -80c~+20c(Supports Ppmv)
- Sf6 Purity：0~100%Sf6(Weight Ratio)
- Inlet Pressure：Less Than 1.0MPa
- Operation Temperature：-30~+50c
- Charging Voltage：220VAC +-10% 50Hz
- Using Time：No Less Than 8 Hours of Continuous Work
- Storage Capacity：60
- Size：300*400*150(mm)
- Transport Package：Plywood Package
- Trademark：EP Hipot Electric
- Origin：Wuhan, China
- HS Code：903180909
- Production Capacity：1000,Year
Description
Measurement accuracyDew point:±0.5ºC(If below 0ºC,sensor displays frost point) SF6 purity:±0.1%,irrelevant of flow SF6 decomposition products: 0.1ppm Inlet pressure ≤1.0Mpa Operation temperature -30~+50ºC Environment temperature ≤90%RH Charging voltage 220VAC±10% 50Hz Using time no less than 8 hours of continuous work Storage capacity 60 Size 300 × 400 × 150(mm) Weight 5.5 kg Operation method Touch Screen Communication RS232 or USB Printing Micro printer
More details on SF6 Gas Analyser please contact EP Hipot Electric, we have professional tech team to design correctly designed products and systems.
