Laboratory Instrument Lab Gas Chromatography Dga Dissolved Gas Analysis Transformer Oil Monitoring System
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Onsite and Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Display：LCD Touch Screen
- Portable：Portable
- Certification：CE, ISO9001
- Type：Dga
Base Info
- Model NO.：EPGC-20Smart
- Screen Display：7-Inch Color Touch Screen
- Display Accuracy：0.1oc
- Oven Lift Rate：Any Stage Platform Program Temperature Rise, up to
- Repeatability of Temperature Program：Less Than 1%
- (Fid) Maximum Operating Temperature：400 Oc
- (Fid) Detection Limit：5*10-12g,S (N-Hexadecane)
- (Fid) Baseline Noise：Less 2*10-14A
- (Fid) Dynamic Linear Range：10 7
- (Tcd) Baseline Noise：Less 10UV
- (Tcd) Maximum Use Temperature：300 Oc
- (Tcd) Sensitivity：S Value Higher Than 9000mv.Ml,Mg (Benzene)
- (Tcd) Baseline Drift：Less 50UV,30min
- Chromatographic Column：One for Measuring H2, Co, CO2, One for Measuring C
- Special Tools and Consumables：Epgc-Smart
- Key Words：Transformer Oil Gas Chromatography Analyser
- Transport Package：Plywood Cases
- Trademark：EP Hipot Electric
- Origin：Wuhan, China
- HS Code：9030332000
- Production Capacity：1000,Year
Description
Thermal conductivity detector (TCD)Maximum use temperature 300ºC Sensitivity: S value ≥9000mv.ml/mg (benzene) Baseline drift: ≤50uv/30min Baseline noise: ≤10uv Dynamic range: 105 Chromatographic column For transformer oil, one for measuring H2, CO, CO2, one for measuring CH4, C2H4, C2H6, C2H2, and one for TCD reference column Ni conversion furnace Convert trace amount of CO CO2 to CH4 and respond in FID Special tools and consumables For EPGC-SMART
More details on Oil Dissolved Gas Analyzer (also called: Transformer Oil Gas Chromatography Analyzer) , please contact EPHipot Electric, we have professional tech team to design correctly designed products and systems.
