• Model NO.：GDWG-V
• Response time：≤2s
• Stability：≤±20ppm, more than 1000hours
• Transport Package：Carton or Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9027100090
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. GDWG-V Response time ≤2s Stability ≤±20ppm, more than 1000hours Transport Package Carton or Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9027100090 Production Capacity 2000PCS/Year

Product Description

General Information

GDWG-V SF6 Gas Leak Detector is infrared red type leak detector (NDIR technology) with double display. It is color OLED display and real-time shows SF6 concentration. It rapidly detects SF6 breaker, GIS leakage point and yearly leakage rate qualitatively and quantitatively. It's a good device suitable for power supply department, installation and overhaul unit, power test institute.


Main application

• High Voltage Switch Equipment
• Rotor vane of helicopter
• Gas transmission system
• To detect fire extinguisher
• Ventilation efficiency research of Buildings
• To detect danger

Advantages

• No radiation.
• No need to replace high pressure high pure argon gas regularly.
• No need to approach high pressure gas.
• No need to replace sensors regularly, cost-effective.
• Stable performance, low maintenance cost. No need to make linear calibration every year.
• No affect by moisture and environment pollution.
• High sensitivity, up to 0.01ppmv.
• When serious leakage or the SF6 gas concentration is up to 100%, it will not be polluted or damaged.

Features

• OLED double display, visual in sunlight.
• Built-in Lithium battery.
• User-defined alarm with sound and light.
• High sensitivity and good stability.
• Fast measurement speed, time is up to 3s.
• Temperature and pressure compensation.
• Only response for SF6 gas, not for other gas.
• Non-gas contact measurement features ensure that no sensor poisoning will occur at any concentration.
• The sensor constant temperature chamber can ensure that the sensor does not have temperature drift at any ambient temperature.
• Small size, easy to carry, suitable for on-site working.
• With gasbag non-slip straps, more comfortable to carry.
• Data storage up to 100groups.
• Super-light aluminum with full shielding shell.
• External package uses engineering plastic, with water-proof, dust-proof.

Specifications

• Measuring principle: Non-dispersive infrared sensor (NDIR)
• Measuring range: 0-2000ppmv SF6 or 0-50ppmv
• Resolution: 0.1ppmv or 0.01ppmv
• Accuracy: ±2%FS(0-1000ppm)
• Repeatability error: ≤±1%
• Sensitivity: 0.1ppmv
• Response time: ≤2s
• Recovery time: ≤5s
• Stability: ≤±20ppm, more than 1000hours
• Zero shift: ≤±1%(F.S/year)
• Linear error: ≤±1%
• Storage temperature: -20~+60ºC
• Operation temperature: -20~+50ºC
• Sampling mode: Built-in electromagnetic diaphragm pump, automatic slot-in type, flow up to 1L/min.
• Working voltage: 220VAC±10%, 50Hz Or Built-in Li-battery, 8hours working.
• Dimension: 140×235×83mm
• Weight: main unit about 1.5kg, hand gun about 0.5kg



•
