Water 0-10% H2so4 Sulphuric Acid Concentration Sensor Analyzer
Shanghai Boqu Instrument Co., Ltd.- After-sales Service：Support
- Warranty：1year
- Electrode Material：High Quality Polysulfone and Platinum
- Material：Polysulfone
- Transport Package：PP Bag ,Paper Box,Sponge,Seaworthy Box
- Specification：SGS
Base Info
- Model NO.：SJG-03
- Trademark：BOQU
- Origin：Shanghai, China
- HS Code：90278099
- Production Capacity：5500PCS,Month
Description
Overview
| 1.Measuring range: concentration: (0~10)% HCL; (0.00~10.00)%H2SO4; (0.00~10.00)%HNO3; temperature: 0~99.9ºC (0~150ºC Option) |
| 2. Intrinsic error of electronic units: concentration: ±1.0%; temperature: ±0.3ºC |
| 3. Range of automatic temperature compensation: 0~99.9ºC |
| 4. Solution tested: 0~99.9ºC, 0.6MPa |
| 5. Intrinsic error of the instrument: concentration: ±2.0% (the error may be less than 0.05% after usual point |
| calibration.) |
| Temperature: ±0.5ºC(0.0ºC≤T≤80.0ºC) |
| 6. Repeatability error of the electronic unit: ±1.0% |
| 7. Stability of the electronic unit: ±1.0%/24h |
| 8. Isolated current output: 4~20 mA (load <750Ω) |
| 9. Output current error: ≤±1%FS |
| 10. Compensation range of the temperature coefficient: (0-10.0)% /ºC (adjustable) |
| 11. Alarm relay: AC 220V, 3A |
| 12. Communication interface: RS485 (optional) |
| 13. Power supply: AC220V±22V, 50Hz±1HZ, DC24V(optional) |
| 14. Protection grade: IP65 |
| 15. Clock accuracy: ±1 minute/month |
| 16. Data storage capacity: l month (1 point/5 minutes) |
| 17. Weight: 0.8kg |
| 18. Overall dimension: 146 (length) x 146 (width) x 108 (depth) mm; dimension of the hole: 138 x 138mm |
| 19. Working conditions: ambient temperature: 0-60ºC; relative humidity <85% |
