Biobase Hot Sale HPLC 0.001ml/Min-10.000ml/Min High Performance Liquid Chromatography for Lab

Biobase Biozone Co., Ltd.

After-sales Service：Online Support
Warranty：1 Year
Appliance：Medical Research
Ray Type：,
Gaspath System：,
Detector：UV,Vis Detector

Base Info

Model NO.：BK-LCI3100
Energy Resolution：,
Spectrometer Detector：,
Stationary Phase：,
Mobile Phase：,
Chromatography Type：Liquid Chromatography
Chromatographic Column Type：,
Chromatographic Column Length：,
Chromatographic Column Diameter：,
Model：Bk-Lci3100
Quantity：1 Set
Flow Rate Range：0.001ml,Min-10.000ml,Min
Flow Accuracy：<+-0.2% (1.00ml,Min, H2O, R.T., 8.5MPa)
Flow Precision：Rsd≤0.075% (1.00ml,Min, H2O, R.T., 8.5MPa)
Maximum Pressure：45MPa
Pressure Accuracy：<+-3.0%
Pressure Pulsation：<0.1MPa
Wavelength Range：190-700nm
Wavelength Repeatability：<0.1nm
Wavelength Accuracy：<+-1.0nm
Band Width：8nm
Response Time：0.0s-5s
Baseline Noise：<+-0.5×10-5au
Drift：<1.0×10-4au,H
Transport Package：Carton or Wooden Case
Specification：0.001mL,min-10.000mL,min
Trademark：,
Origin：Shandong
Production Capacity：1000

Description

Overview

Product Description

Product Parameters

Model

BK-LCI3100

BK-LCGH3100

BK-LCQL3100

High Pressure Constant Flow Pump

Quantity

1 Set

2 Set

1 Set

Flow Rate Range

0.001mL/min-10.000mL/min

Flow Accuracy

≤±0.2% (1.00ml/min, H2O,R.T.,8.5MPa)

Flow Precision

RSD≤0.075% (1.00ml/min, H2O,R.T.,8.5MPa)

Maximum Pressure

45MPa

Pressure accuracy

≤±3.0%

Pressure pulsation

≤0.1MPa

UV/VIS

Detector

Wavelength Range

190-700nm

Wavelength Repeatability

≤0.1nm

Wavelength Accuracy

≤±1.0nm

Band Width

8nm

Response Time

0.0s-5s

Baseline Noise

≤±0.5×10-5AU

Drift

≤1.0×10-4AU/h

Path length

10 mm(analytical cell)

Light Source

Deuterium Lamp

Low-Pressure Gradient Unit

Integrated vacuum degasser

4 channel

Composition Rang

0-100%

Composition Precision

≤0.2% RSD

Composition Accuracy

≤±2.0%

Data-processing Workstation

Internal and external standard calculation methods

Automatically displays, prints, exports and starts other programs after the completion of a measurement.

3100 System Kits

1 Set

Power Supply

AC110/220V±10%, 50/60Hz

Optional Accessory

Column Oven, Autosampler, Degasser, Diode Array Detector, Refractive Index Detector, Evaporative Light Scattering Detector, Fluorescence Detector

Package Size(W*D*H)

600*440*380mm*4

Gross Weight

68kg
