• Model NO.：TP-130
• Trademark：TOP
• Origin：China
• HS Code：9027809900
• Production Capacity：200 Sets,Month

Basic Info.

Model NO. TP-130 Trademark TOP Origin China HS Code 9027809900 Production Capacity 200 Sets/Month

Product Description

High Quality ASTM D1838 Copper Strip Corrosion Tester for LPG(TP-130)


Application:
ASTM D1838 Standard Test Method for Copper Strip Corrosion by Liquefied Petroleum (LP) Gases
This ASTM D130 copper strip corrosion test instrument complies with GB / T5096, applicable to assessing the extent of aviation gasoline, jet fuel, motor gasoline, kerosene, diesel, natural gasoline, lubricants and other petroleum products for copper corrosion.
The instrument is designed and manufactured in accordance with the requirements of the People's Republic of China standard SH/T 0232.

Features
Control mode: temperature control system, digital display temperature control accuracy.
Stainless steel bath, housing, anti-rust.
It adopts imported compressor refrigeration, stable temperature and fast cooling speed.
The fastening device and instrument of the instrument test cylinder adopt an integrated structure.
The instrument can hold two test cylinders, which can be used separately or simultaneously.
Adopt advanced foreign PID temperature control technology, PID parameters can be self-tuned.


Technical parameters:
1. Suitable for aviation gasoline, jet fuel, motor gasoline, kerosene, diesel, natural gasoline, lubricants and other petroleum products, assess the extent of corrosion on copper
2. Bath temperature: room temperature ~ 200 ºC
3. Temperature accuracy: ± 0.1 ºC
4. Temperature control point: 37.8 ºC
5. Heating power: 1KW
6. Temperature control: microprocessor-based intelligent instrument temperature control, digital display of temperature, temperature correction, automatic timer, beeper reminder
7. Instruments Material: imported brushed stainless steel
8. Dimensions: 450 * 300 * 600
9. Weight: 20kg
