• Model NO.：BK-UV1800
• Spectrometer Detector：SDD
• Stationary Phase：Liquid Solvent
• Mobile Phase：Liquid
• Chromatography Type：Liquid Chromatography
• Chromatographic Column Type：Convetional Analytical Column
• Chromatographic Column Length：10~20cm
• Chromatographic Column Diameter：1~2mm
• Transport Package：Carton Package
• Specification：560*430*320mm 12kg
• Trademark：BIOBASE
• Origin：China
• HS Code：9027300000
• Production Capacity：10000 Pieces,Year

Model

BK-UV1800

BK-UV1800PC

Optical System

Single Beam, Grating 1200 lines/mm

Wavelength Range

190~1100nm

Spectral Bandwidth

2nm

Wavelength Accuracy

± 0.5nm

Wavelength Repeatability

≤ 0.3nm

Photometric Accuracy

± 0.002A (0~0.5Abs), ± 0.004A (0.5~1.0Abs), ± 0.5% T (0~100% T)

Photometric Repeatability

0.001Abs (0~0.5Abs), 0.002Abs (0.5~1.0Abs), ≤ 0.2% T (0~100% T)

Stray Light

≤ 0.05% T @ 360nm; 220nm

Stability

± 0.001A / h @ 500nm

Baseline Flatness

± 0.002A

Noise

± 0.0005A

Display

480 * 272 65 thousand true color TFT LCD

Photometric Mode

T, A, C, E

Photometric Range

0~200% T, -0.301~3.0A

Detector

Silicon Photodiode

Light Source

Deuterium Lamp, Tungsten Lamp

Input

Membrane Keypad

Output

USB  Print and data output, Connect PC

Standard Accessories

10mm glass cuvette *4 units       10mm quartz cuvette *2 units

Optional Accessories

Single cell holder,General cell holder,Test tube holder,Solid sample holder,Deuterium lamp,Halogen lamp,4-place Cell holder,Printer,Water-jacketed cell holder,Reflection accessory 5°,Auto 8-cell changer,Micro cell holder,Water-jacketed cell holder,Constant-temperature system

Power Supply

AC110V/220±10% ,60/50Hz

Packing Size(mm)

620*500*370

Gross Weight(kg)

18
