• Model NO.：GasBadge Pro
• Gas：O2
• Type：Infrared Absorption Analyzer
• Sensors：Co, H2s, O2, No2, So2, Nh3, Ci2, Cio2, pH3, Hcn
• Data Logging：1 Year Continuous Storage of Data
• Temperature Range：-40 ºC to 60 ºC
• Humidity Range：0% to 99% Rh (Non-Condensing)
• IP Rating：IP64
• Transport Package：Carton ,Wooden Box
• Origin：China
• HS Code：9027100010
• Production Capacity：5000pieces,Year

Overview Product Description

Built to Industrial Scientific's highest quality and reliability standards, GasBadge® Pro provides a lifetime of gas hazard protection with more features than any other single gas monitor available. Interchangeable "smart" sensors enable the GasBadge Pro to be quickly adapted to monitor unsafe levels of oxygen or any one of the following toxic gases: carbon monoxide, hydrogen sulfide, nitrogen dioxide, sulfur dioxide, chlorine, chlorine dioxide, phosphine, ammonia, hydrogen cyanide and hydrogen. GasBadge Pro communicates directly via an infrared interface to optional accessories like the DSX Docking Station, Datalink and infrared printer to further simplify and automate calibration, function (bump) testing and data downloading. Standard STEL and TWA readings, and datalogging of up to one year of survey data are featured along with an event-logger that records the past 15 alarm events. Housed in a rugged enclosure, the monitor is immune to RF, water resistant and extremely durable. A protective concussion-proof overmold protects the unit from extreme abuse in a variety of harsh industrial environments. It's simple and intuitive four-button navigation allows easy access to setup, operation and calibration functions.

Features:

• Interchangeable "smart" sensors monitor oxygen or any one of many toxic gases
• One-year data logging capacity (minimum)
• Standard STEL and TWA
• iNet® ready and DSX™ Docking Station compatible



Detailed Photos



Product ParametersCASERugged, water-resistant polycarbonate shell with protective concussion-proof overmold. RFI resistantDIMENSIONS9.4 x 5.08 x 2.79 mm (3.7 x 2 x 1.1 in )WEIGHT85 g (3 oz)SENSORSCO, H2S, O2, NO2, SO2, NH3, CI2, CIO2, PH3, HCN, H2, CO/H2 LowBATTERY RUN TIMEUser replaceable 3V, CR2 Lithium battery, 2,600 hour run time, typicalDATA LOGGING1 year continuous storage of dataTEMPERATURE RANGE-40 ºC to 60 ºC (-40 ºF to 140 ºF), typicalHUMIDITY RANGE0% to 99% RH (non-condensing), typical



Certifications

ANZEx: Ex ia I/IIC T4
ATEX: Ex ia I/Ex ia IIC T4; Equipment Group/Category I M1/II 1G
China Ex: Ex ia I/IIC T4
CMA: Ex ia I
CSA: Cl I, Gr A-D, T4; Ex ia IIC T4
KC: Ex ia I/IIC T4
IECEx: Ex ia I/IIC T4
INMETRO: Ex ia IIC T4
UL: Cl I, Div 1, Gr A-D, T4; Cl II, Gr E-G
