• Model NO.：PHG-2091
• Specification：SGS
• Trademark：BOQU
• Origin：Shanghai, China
• HS Code：90278099
• Production Capacity：3200PCS,Month

Technical Indexes1. Measuring range: 0~14.00pH, Resolution: 0.01pH
2. Precision: 0.05pH, ± 0.3º C
3. Stability: ≤ 0.05pH/24h
4. Automatic temperature compensation: 0~100º C(pH)
5. Manual temperature compensation: 0~80º C(pH)
6. Output signal: 4-20mA isolated protection output, dual current output
7. Communication interface: RS485(selection)
8. Output control mode: ON/OFF relay output contacts
9. Relay load: Maximum 240V 5A; Minimum l l5V 10A
10. Relay delay: Adjustable
11. Current output load: Max. 750Ω
12. Insulation resistance: ≥ 20M
13. Working voltage: 220V± 22V, 50Hz± 0.5Hz
14. Overall dimension: 96(length)x96(width)x110(depth)mm
      Dimension of the hole: 92x92mm
15. Weight: 0.6kg
16. Working condition:
      Ambient temperature: 0~60º C, air relative humidity: ≤ 90%

Except for the earth magnetic field, there is no interference of other strong magnetic field around.

Standard configuration One secondary meter, the mounting sheath of immerged (selection), one PH electrode, three packs of standard buffer solution (for PH4.00, 6.86 and 9.18 respectively).


Ordering guide:

1. To inform whether the electrode provided is a dual or ternary complex.
2. To inform the length of the electrode cable (default as 5m).
3. To inform the installation type of the electrode:
    Flow-through, immerged, flanged or Pipe-based

FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days
if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: We cann offer the sample, it is extra

Q: What is your terms of payment ?
A: 100% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact us as below:
Contact: Jori Liu
Mobile: +86 17507082182
