Gd-3536D ASTM D92 Cleveland Open Cup Flash Point Tester Apparatus
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Usage：Automatic Coc Flash Point Tester
- Apparatus：Automatic Cleveland Open Cup Flash Point Tester
- Function：Automated Cleveland Open Cup Flash Point Apparatus
- Application：Flash Point and Fire Point Test
- Testees：Petroleum Products, Bituminous Materials
- Measurement Range：Room Temperature~400c
Base Info
- Model NO.：GD-3536D
- Type：Fully Automatic
- Overall Power Consumption：No More Than 500W
- Reference Standard：ASTM D92, GB,T 3536, ISO 2592
- Warranty：1 Year
- Transport Package：Standard Wooden Case
- Specification：ISO Certificate
- Trademark：Gold
- Origin：Chongqing of China
- HS Code：9031809090
- Production Capacity：100sets,Month
Description
Igniting modeElectric ignition Gas flame diameter: 3.2mm ~ 4.8mm 5 Ambient temperature (10 ~ 40) °C 6 Relative humidity ≤ 80% 7 Maximum power consumption 500W 8 Dimension 520mm×380mm×310mm 9 Weight 13kg
Full Set:
Real Picture:
Full Set:
| No. | Name | Unit | Quantity | Remark |
| 1 | Main unit | Set | 1 | |
| 2 | Cleveland oil cup | Piece | 1 | We can provide more if you required. |
| 3 | Ignition device | Set | 1 | |
| 4 | Thermometer | Piece | 1 | -6°C~400 °C, graduated scale is 2 °C |
| 5 | Thermometer support | Set | 1 | |
| 6 | Power supply wire (250 V 6 A) | Piece | 1 | |
| 7 | Fuse 5 A (Φ5×20) | Piece | 2 | |
| 8 | Latex tube Φ6 | Meter | 1.5 | Could not be used as coal gas tube |
| 9 | Joint for coal gas tube | Piece | 1 | Connect coal gas tube and latex tube |
| 10 | Extinguishing cover | Piece | 1 |
Real Picture:
