Online Industrial pH Sensor for General Industrial Process (ASP2121)

Nengshi Analytical Sensor Co., Ltd.
  • Display：pH Meter
  • Appliance：Food Analysis, Medical Research, Biochemistry, General Industrial Process
  • Portable：Portable
  • Certification：RoHS
  • Type：pH Sensor
  • Material：Glass

Base Info

  • Model NO.：ASP2121
  • Thermistor：No
  • Operating Temperature：0-110ºC
  • Operating Pressure：0-0.6MPa
  • Plug：Spc
  • Thread：Pg13.5
  • Transport Package：Paper Box
  • Specification：12*120
  • Trademark：NENGSHI
  • Origin：Wuhan China
  • HS Code：90279000
  • Production Capacity：5000 Pieces,Year

Description

Technical feature:·Adoption of the most advanced large Teflon diaphragm ,which makes the sensor with stable liquid juntion.·Strong anti-interference ability,it is not easy to be polluted and blocked,so it has a  long life.·The reference system is filled with the high polymer; convenient use; it is unnecessary to refilling electrolyte.·Sensitive response of the sensor ,the 95% measured value  can be reached up in several seconds.·pH range: 0~14pH the temperature range:0~110ºC.·Pressure resistance of the sensor:0.6MPa and the zero point E0=7pH .·The external dimension of the sensor is φ12x120, 225,360 or other dimensions. The common industrial process includes the following fields :
1. Chemical industry
2. Petrochemical industry
3. Sugar industry
4. Swimming pool water, sea water , underground water
5. High temperature and strong acid occasion ,high temperature and strong base occasion
6. Other industry
· Model: ASP2121 combination sensor.
· Direct use with various pH meters as a complete set.
· Plug-in connection, convenient to installation and replacement.
· pH range:0-14; zero point: E0=7pH; Temperature rang: 0-110ºC.
· pressure range:0.6MPa.
· The external dimension of the sensor isΦ12×120,225 or other size.
· It can be installed with the thread PG13.5.
· The outer tube material:glass.
