Two-Wire System Online Water Conductivity Transmitter (DDG-2519)
Shanghai Boqu Instrument Co., Ltd.- After-sales Service：Provided
- Warranty：Provided
- Measuring Range：0~20us,Cm
- Measurng Range 2：0~200us,Cm
- Measuring Range 3：0~2000us,Cm
- Design：Bran-New Design Pattern
Base Info
- Model NO.：DDG-2519
- Transport Package：Carton Box
- Specification：SGS, CE, ISO9001
- Trademark：BOQU
- Origin：Shanghai
- HS Code：9027809900
- Production Capacity：100piece,Month
Description
Overview
Certifications
Technical Indexes
1. Working conditions
A. Ambient temperature: 0~55ºC
B. Relative humidity: <85%
C. Power supply: 24 VDC± 5%
D. Solution temperature tested: 5~55 ºC
2. Conductivity measuring range:
K=0.01 electrodes: 0~20.0 µ S/ cm
K=0.1 electrodes: 0-200.0 µ S/ cm
K=1.0 electrodes: 0-2000 µ S/ cm
Temperature measuring range: 0-85ºC
3. Intrinsic error of conductivity measurement: ± L%F. S
Intrinsic error of temperature measurement: ± 0.5 ºC
4. Temperature compensation range and influence error: 5~55 ºC, ± 0 5%F. S
5. Isolated current output and intrinsic error: 4-20mA (RL≤ 500Ω ) ± 0.5%F. S
6. Installation of electrode: Pipeline installation, circulation tank installation
Technical Indexes
1. Working conditions
A. Ambient temperature: 0~55ºC
B. Relative humidity: <85%
C. Power supply: 24 VDC± 5%
D. Solution temperature tested: 5~55 ºC
2. Conductivity measuring range:
K=0.01 electrodes: 0~20.0 µ S/ cm
K=0.1 electrodes: 0-200.0 µ S/ cm
K=1.0 electrodes: 0-2000 µ S/ cm
Temperature measuring range: 0-85ºC
3. Intrinsic error of conductivity measurement: ± L%F. S
Intrinsic error of temperature measurement: ± 0.5 ºC
4. Temperature compensation range and influence error: 5~55 ºC, ± 0 5%F. S
5. Isolated current output and intrinsic error: 4-20mA (RL≤ 500Ω ) ± 0.5%F. S
6. Installation of electrode: Pipeline installation, circulation tank installation
