• Model NO.：TP-126
• Trademark：TOP
• Origin：China
• HS Code：9027809900
• Production Capacity：200 Sets,Mongth

Basic Info.

Model NO. TP-126 Trademark TOP Origin China HS Code 9027809900 Production Capacity 200 Sets/Mongth

Product Description

Factory Oil ASTM D5191 D323 Reid Pressure Tester for liquid fuels(TP-126)

Product Application
ASTM D5191 Standard Test Method for Vapor Pressure of Petroleum Products and Liquid Fuels (Mini Method)
This instrument is designed and manufactured under the requirements of standard GB/T8017 "Determination of
Petroleum Products Vapor Pressure (Reid Method)" which promulgated by The People Republic
of China, Applicable to test the vapor pressure of gasoline, volatile crude oil and other petroleum
products.


Product Features

The instrument uses floor structure, the workbench made of stainless steel, reasonable scientific
instrument design, elegant appearance, easy to operation, complete accessories.
Adopt digital temperature control, uniform bath temperature, high-precision temperature  control, fully meet the requirements of the test.
Equipped with two precision pressure gauges to detect the gas pressure inside the bomb. The accuracy
         of  gas pressure measurement up to ±0.4%.
      5. Equipped with a single opening and a double opening vapor pressure bomb, which can be placed in the
          instrument test port for synchronization test.

Technical Parameter

Power supply: AC 220V±10%, 50Hz;
Bath heating power: 1600W;
Bath temperature range: room temperature~90ºC;
Water bath temperature control accuracy: ±0.1ºC;
Pressure gauge accuracy: ±0.4%;
Ambient temperature: -10~35ºC;
Relative humidity: ≤85%;
Power consumption: less than 1700W
