Variable Frequency Series AC Resonant Test System for Cable Testing

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service:Response in 12 Hours
  • Warranty:12 Months
  • Power Supply:380V±10%, Three-Phase 50Hz,60Hz
  • Rated Voltage Output:0-1000kv
  • Max Output Capacity:0~6400kVA
  • Test Frequency Range:30~300Hz

Base Info

  • Model NO.:RTS
  • Continuous Duty Cycle:60min
  • Quality Factor:30-80
  • Frequency Setting Resolution:0.1Hz
  • Test Voltage Waveform:Sine Wave
  • Display:Digital
  • Function:AC High Voltage Withstand Test for Cable,Gis etc
  • OEM Service:Available
  • Transport Package:Plywood Case
  • Specification:Red
  • Trademark:AI
  • Origin:China
  • HS Code:9031809090
  • Production Capacity:50 Sets,Month

Description

Basic Info.

Model NO. RTS Continuous Duty Cycle 60min Quality Factor 30-80 Frequency Setting Resolution 0.1Hz Test Voltage Waveform Sine Wave Display Digital Function AC High Voltage Withstand Test for Cable,Gis etc OEM Service Available Transport Package Plywood Case Specification Red Trademark AI Origin China HS Code 9031809090 Production Capacity 50 Sets/Month

Product Description

I. Introduction:

The AC Resonant Test System is mainly for cable, main transformer neutral point, GIS, switches whose rated voltage not more than 110kv and other AC high voltage withstand test.
The AC Resonant Test System consists of variable frequency power supply, excitation transformers, reactors, capacitive voltage divider.



II.Main Features

★The required power capacity is greatly reduced.

★The weight and size of the device is greatly reduced.

★Improve the waveform of output voltage.

★Prevent high short-circuit current from damaging the fault point.

★It does not appear any recovery over voltage when the test specimen was breakdown. High voltage disappears immediately and the arc
extinguishes immediately when the system loss resonance condition.

★The protection function of overvoltage, over current, zero start, and the system flashover.

★ This AC Resonant Test System has three operating modes: automatic mode, manual mode, automatic tuning manually boost mode.

★Test records can be saved and identified with digital ID.

★Based on the DSP platform technology, the AC Resonant Test System can easily increase or decrease function and upgrades.



    III. Package List of AC Resonant Test System


    Power supply380V±10%, three-phase 50Hz/60Hz
    Rated voltage output0~1000KV
    Max output capacity0~6400KVA
    Test frequency range30~300HZ
    Continuous duty cycle60min
    Quality factor30~80
    Frequency setting resolution0.1HZ
    Test voltage waveformsine wave, waveform deviation factor : ≤1%
    Temperature0~50°C
    Humidity≤ 90%RH


    Factory overview

    Variable Frequency Series AC Resonant Test System for Cable Testing
    Customer Feedback

    Chile
    Variable Frequency Series AC Resonant Test System for Cable TestingGermany

    Variable Frequency Series AC Resonant Test System for Cable Testing
    USA
    Variable Frequency Series AC Resonant Test System for Cable Testing
    Transporation
    Variable Frequency Series AC Resonant Test System for Cable Testing

    FAQ

    1.What's the delivery time?
    About 25 working days.

    2.What's your payment terms?
    30% paid by T/T in advance,70% paid by by T/T before shipping.

    3.What's your guarantee terms?
    The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

    4.Can you supply training?
    We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
