ASTM D5882 Standard Low Strain Dynamic Pile Tester (PIT)
Beijing Samyon Instruments Co., Ltd.- After-sales Service：24hours
- Warranty：One Year
- Standards：ASTM D5882
- Sampling Frequency：48kHz, 96 kHz,144 kHz
- Sample Size：4k
- Power：Internal Battery
Base Info
- Model NO.：LPT
- Display：High-Contrast Touch Screen Display
- Transport Package：Carton Case
- Specification：SGS
- Trademark：SAMYON
- Origin：Cn
- HS Code：9031809090
- Production Capacity：100sets Per Month
Description
1. Follow the specifications:
ASTM D5882 Standard Test Method for Low Strain Integrity Testing of Piles
JGJ106-2003 (China) Technical code for testing of building foundation piles
2. Parameters:
1). Size: 62 * 172 * 225 mm.
2). Weight: 2.0 kg.
3). High-contrast touch screen display.
4). Temperature range:
Operating Range: 0° to 40° C; Storage Range: -20° to 65° C.
5). Powered by internal battery (6 hours duration).
3. Functional:
1). The LPT is used for Integrity pile testing and judging defect position
2). Automatic data storage
3). Signal amplification capability
4). Data can be averaged over a variable number of blows.
5). Variable signal amplification over time
6). 24-bit A/D converter
7). Sample size: 4k
8). Sample Frequency: 48kHz, 96 kHz,144 kHz
