• Model NO.：GT903-C2H4
• Analog Digital Output：4-20mA Output(0-5V,0-10V Optional)
• Material：Aluminum,Explosion and Corrosion Proof
• Operating Pressure：0-200kpa
• Screen Size：2.4 Inch LCD HD Color Screen
• Explosion Proof Sign：Exdll CT4 (Ia)
• IP Rating：IP 66
• Power：4000mA High Capacity Polymer Rechargeable Battery
• Modbus Digital Output：RS485 Output
• Relay Output：2-3 Relays Output
• Sampling：Diffusion
• Transport Package：Size: 26*21*14cm
• Specification：Product size: 21*8*7cm
• Trademark：Korno or customized
• Origin：China
• HS Code：9027100010
• Production Capacity：10000,Month

Portable,C2H4 EthyleneDetection Range:0-10,50,100,200,1000,2000PPMResolution:0.01PPM(0-100PPM),0.1PPM(0-2000PPM)Temperature and  relative humidity:
(Optional)Temperature detection range:-40 ~ 120ºC
Humidity detection range:0-100%RH
 Detection pattern:Pumping, the flow rate is adjustable.Detection Accuracy:≤±3%F.SLinearity Error:≤±1%F.SReaction Time:≤20 S(T90)Zero drift:≤±1%(F.S/Year)Detection Method:Real-time detection mode, timing detection mode and cycle detection mode can be switch freelyStorage Method:Automatically saving and manually saving is available,
Up to 30,800 group data ,user can view history data on the display.Explosion Proof Sign:Exdll CT4 (IA)Case material:ABS+PCIP rating:IP66Operating Temperature:-30 ~ 60ºC(-22~144ºF) Power:4000mA high capacity polymer rechargeable batteryOperating Humidity:≤90%RH,Non-condensingDimensions / Weight:180*88*55 mm(L×W×H)
0.5 Kg(net weight)Operating Pressure:-30Kpa ~ 100KpaStandard Accessories:-Portable aluminum Case
-User manual
-Certification
-USB charger+Data cable
-Calibration coverOptional Accessories:-Vapor filter
-Hose
-Sampling handle(stainless steel ,approx 60cm)
>>>Details:



>>>Our service:

1) All products and accessories have been 100% tested before shipping.
2) We provide 12-Mounths warranty for non-deliberate damage.
3) OEM & ODM are welcomed~

>>>Contact US:
