• Model NO.：HZWS-509
• Resolution：Dew Point 0.1ºC or 0.1UL,L
• Working Voltage：220VAC±10% 50,60Hz
• Temperature：-25~+60ºC
• Relative Humidity：≤90%Rh
• Measurement Accuracy：≤0.5ºC
• Repeatability：±0.5ºC
• Storage Temperature Level：-40~+70ºC
• Weight：About 3.8kg
• Transport Package：Wooden Box with Wrapping Film
• Specification：285x320x133mm³
• Trademark：United
• Origin：Wuhan, China

Basic Info.

Model NO. HZWS-509 Resolution Dew Point 0.1ºC or 0.1UL/L Working Voltage 220VAC±10% 50/60Hz Temperature -25~+60ºC Relative Humidity ≤90%Rh Measurement Accuracy ≤0.5ºC Repeatability ±0.5ºC Storage Temperature Level -40~+70ºC Weight About 3.8kg Transport Package Wooden Box with Wrapping Film Specification 285x320x133mm³ Trademark United Origin Wuhan, China

Product Description

Production Description:
HZWS-509 Intelligent SF6 micro water detector introduced Finland Vaisala humidity sensor with high precision and high stability. It has the advantages of high accuracy and good repeatability, fast test speed, small drift.

Product Features:
1.Easy to operate, convenient to carry.
2.Unique large screen display and large storage function.
3.Anti pollution, anti interference.
4.Good repeatability, quick response, high sensitivity and good stability.
5.Origination of curve display and electric quantity display.
6.Automatic conversion to 20ºC standard value.

Product Parameters:

Measurement Range	Dew point-80ºC~+20ºC or -60ºC~+60ºC(with ppmv automatic conversion function)	Measurement Accuracy	≤0.5ºC
Response Time	63%[90%]; +20→-20ºCTd 5s[45s]; -20→-60ºC Td 10s[240s]	Repeatability	±0.5ºC
Resolution	Dew point 0.1ºC or 0.1ul/l	Storage Temperature Level	-40~+70ºC
Working Voltage	220VAC±10% 50/60Hz, AC and DC two purpose, overcharge protection, continuous working	Dimension	285x320x133mm³
Operation Environment	Temperature: -25~+60ºC Relative humidity: ≤90%RH	Weight	About 3.8kg
