SA8320 32-CH Logic Analyzer

Shijiazhuang Suin Instruments Co., Ltd.
  • Warranty：18 Months
  • OEM/ODM Service：Yes
  • Transport Package：Carton
  • Specification：430*380*290 mm
  • Trademark：SUIN
  • Origin：China

Base Info

  • Model NO.：SA8320
  • HS Code：9031809090
  • Production Capacity：30000 Set,Year

Description

 SA8320InputInput Channel32 data sampling channels, 2 external clock channelsThreshold   Voltage6 independent and adjustable threshold voltagesAdjustable Range: -6V ~ +6VResolution: 0.1VInput ImpedanceR ^ >100 kΩ, C ^ <8 pfSample/MemorySampling RateTiming Rate1Hz ~ 100MHz (Period 10ns ~ 1s), Resolution: 10nsState Rate1Hz ~ 35MHzSampling Phaserise edge, fall edgeMemory Depth256k bytes / channelTrigger Trigger Condition32 bits trigger level, 32 bits trigger comparandEvent Count1 ~ 999Memory Delay1 to 256k sample cyclesPattern GeneratorPattern TypeCH00 to CH15 are counters with   adding 1,
CH16 to CH29 are shift pulse
