Biobase Portable Leaf Chlorophyll Meter
Biobase Meihua Trading Co., Ltd.- After-sales Service:Online Technical Support
- Warranty:12 Months
- Element:Leaf
- Analysis:Photoelectric Colorimetry
- Display:Digital
- Application:Agriculture
Base Info
- Model NO.:CM-B
- Frequency:50±1HZ
- Performance:Automation
- Function:Test
- Weight:1kg
- Power Source:AC220V±22V
- Customized:Non-Customized
- Measuring Area:2mm*2mm
- Measuring Mode:2-Wavlength Concentration Difference of Optical
- Transport Package:Carton Package
- Specification:270*210*140mm
- Trademark:BIOBASE
- Origin:China
- Production Capacity:10000 Set,Year
Description
Chlorophyll Meter is able to measure chlorophyll content of plants and leaf temperature. Chlorophyll content and leaf nitrogen content have a very close relationship. Thus, chlorophyll content can reflect plants demand for nitro. Using the instrument can do go to put nitrogen fertilizer reasonably, improve utilization of nitrogen and protect environment.
Features:
* Enter the name of the plant, the standard nitrogen content and utilization, the standard fertilizer can be directly calculated.
* Chlorophyll, leaf temperature are displayed on same screen at the same time, and can be stored at the same time.
* USB interface can be connected to the computer to export the measured data, to facilitate the management and analysis of plant nutrients. (Only for CM-B)
Model
CM-A
CM-B
Measuring area
2mm*2mm
Measuring Mode
2-wavelength concentration difference of optical methods
Sensors
Silicon semiconductor photodiode
Display Mode
Measuring value: 3 digits liquid crystal display;
Measuring times: 2 digits liquid crystal display
Min Measuring Interval
<3s
Measuring Range
0.0-99.9 SPAD, -10~99.9°C
Accuracy
±3.0 SPAD; ±0.5°C
Repeat
±0.3SPAD; ±0.2°C
Power Supply
4.2V -2000Mah rechargeable Li battery
Memory Capacity
30Kb, automatically calculate and show the average
Packing Size(W*D*H)
270*210*140mm
Gross Weight
1.0kg
