5A /10A / 20A / 50A Portable Transformer Winding Direct Current DC Resistance Tester Winding Resistance Meter
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Phase：Single & Three Phase
- Max. Test Current：Single Phase: 1A, 5A, 10A, 20A, 20athree Phase: 1
- Resolution：1μΩ
- Max. Error：0.2%Rdg+2D
- Voltage Output：20V
- Power Supply：AC220V±10%% 50Hz,60Hz
Base Info
- Model NO.：GDZC
- Working Environment：-10ºC-+40ºC Rh≤85%
- Delivery Time：7 Days
- MOQ：1 Set
- Certificate：ISO 9001, Ce
- Transport Package：Standard Wooden Case
- Trademark：GOLD
- Origin：China
- HS Code：9030849000
- Production Capacity：200 Sets , Month
Description
(SINGLE&THREE PHASE)
1A,5A,10A,20A, 40A
Three phase:
1A, 5A, 10A, 20A
10mA: 1Ω~2KΩ
1A: 10mΩ~20Ω
5A: 1mΩ~4Ω
100mΩ~100Ω(200mA)
10mΩ~20Ω(1A)
4mΩ~8Ω(2.5A)
1mΩ~2Ω(10A)
100μΩ-400 mΩ(50A)
50μΩ-200mΩ(100A)
10mΩ~20Ω(1A)
1mΩ~4Ω(5A)
1mΩ~2Ω(10A)
1mΩ~1Ω(20A)
1mΩ~0.5Ω(40A)
Three-phase:
10mΩ~6Ω(1A, each phase)
1mΩ~1Ω(5A, each phase)
1mΩ~0.6Ω(10A, each phase)
1mΩ~0.3Ω(20A, each phase)
- Product Show:
