• Model NO.：MMS
• Gas Supplies：Oxygen and Acetylene
• Total Power：200W
• Caliber of Welding Tip：(1.2±0.1)mm
• Fabric′s Preload Tension：175g±0.5g
• Display：LCD
• Application：Protective Clothing Testing
• Color：White
• Language：English
• OEM Service：Available
• Transport Package：Plywood Case
• Specification：Stainless steel
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：10 Sets,Month

Basic Info.

Model NO. MMS Gas Supplies Oxygen and Acetylene Total Power 200W Caliber of Welding Tip (1.2±0.1)mm Fabric′s Preload Tension 175g±0.5g Display LCD Application Protective Clothing Testing Color White Language English OEM Service Available Transport Package Plywood Case Specification Stainless steel Trademark AI Origin China HS Code 9031809090 Production Capacity 10 Sets/Month

Product Description

Introduction
This Molten Metal Splashes Impact Test Apparatus is designed according to EN348 and ISO 9150,and it can meet requirements of Chinese standard GB8965.2-2009 "Protective clothing for welders" and GB/T 17599-1998 "Determination of behaviour of materials on impact of small splashes of molten metal".

Projections of molten metal drops at a point on a vertical oriented test specimen and measurement of the number of the drops required to cause a 40ºC temperature rise in a sensor behind the specimen.

Features
1.This Molten Metal Splashes Impact Test Apparatus is made up of burner,sample frame,welding rod driving device,burner flux controller,HMI device.
2.Oxy-acetylene torch is used to melt metal strip,caliber of welding tip is (1.2±0.1)mm
3.The step motor drives metal strip,and it can set its running speed.
4.Molten guiding device is supplied with high temperature resistant anti-sticking guide slot,45°angel.
5.Temperature sensor is used to measure temperature rising of sample's back.
6.The Molten Metal Splashes Impact Test Apparatus is supplied with heavy copper hammer to set fabric's preload tension 175g±0.5g.
7.Data of temperature rising can be recorded automatically,and the molten drop numbers should be recorded by operator.


Introduction of main machined parts

No.	Name	Craft
1	Contact parts of burner	Stainless steel machined as per standard
2	Auxiliary fixtures	Aluminum processing or stainless steeel
3	Other auxiliary facilities	Thickness of iron plate is 1.5mm ,seamless welded cabinet with baking finish for cars

Main Components of Molten Metal Splashes Impact Test Apparatus

No,	Name	Remark
1	Operation method	Touch screen operation
2	Software	Designed by AIC
3	PLC	Delta DVP 16EC00T3
4	Touch Screen	Weinview SK-043AE
5	Motor	Speed adjustable 5GU-90W/reinforced single phase
6	Acetylene burner	Standard part
7	Temperature display	Delta



Customer Feedback

Germany

USA

Transporation

FAQ
1.What's the delivery time?
About 2 months .

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
