Acid Gas Testing Equipment Combustion Analyzer IEC 60754 for Wire

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Item Name：Acid Gas Testing Equipment Combustion Analyzer
  • Standard：IEC 60754
  • Application：Combustion Analyzer IEC 60754 for Wire
  • Activated Carbon (Air Filter)：Filter Air Through a Filter
  • Pyrex Pipeline：Users Can Easily Insert Sample Into The Prius
  • Combustion Boat Moving System：Combustion Boat Moves Automatic

Base Info

  • Model NO.：GD-IEC60754
  • The Mode Switching：Mode Switch
  • Timer：IEC 60754-1 & IEC 60754-2 Time Measuring Device
  • Drawer：Used to Store Part of The Box
  • Temperature Indicator：Show The Furnace Core Temperature
  • Permanent Magnetic Stirrer：The Agitator Is Used to Measure The Combustion Gas
  • Dimension：1500mm(W)*500mm(D)*600mm(H)
  • Power：110V AC 60Hz , 230V AC 50Hz, 15A
  • Weight：About 60kg
  • Ambient Temperature: Operating：10 to 35 Degree
  • Transport Package：Standard Wooden Case
  • Trademark：GOLD
  • Origin：Chongqing China(Mainland)
  • HS Code：9031809090
  • Production Capacity：500 Sets, Year

Description

IEC 60754-1Test on gases evolved during combustion of materials from cables - Part 1: Determination of the amount of halogen acid gasIEC 60754-2Test on gases evolved during combustion of electric cables - Part 2: Determination of degree of acidity of gases evolved during the combustion of materials taken from electric cables by measuring pH and conductivityKS C IEC 60754-1Tests on gases evolved during combustion of electric cables - Part 1: Measurement of the amount of halogen acid gasKS C IEC 60754-2Tests on gases evolved during combustion of electric cables - Part 2: Corrosiveness test by generating combustion gasesKWS 409Wire of Fire Resistance (Fire-Resistance) - 5.12 Causticity for Combustion gas



Features:

1. Acid Gas Testing Equipment Combustion Analyzer IEC 60754 for Wire is designed with optimized structure, logical layout and easy to operate.

2. All the fixture are made of stainless steel.

3. The effective length of the tube-type furnace is 500mm to 600mm, inner diameter is 40mm to 60mm, with adjustable electric system.

4. Equipped with imported thermocouple from United States.

5. The size of the combustion boat is length 45mm to 100mm, with 12mm to 30mm, depth 5mm to 10mm.

6. The electrical conductivity measuring range is 0.01uS/mm to 100uS/mm.

7. The control system using an electronic temperature control, intelligent control tube furnace temperature.

8. Equipped with two gas collection bottles.

9. Equipped with a PH valued and conductivity detector, with an electronic display and an electrode.

10. Air flow meter is equipped with silicon dioxide fire pipeline to prevent corrosion by the gas.

11. Activated carbon (air filter): filter air through a filter.

12. The silicone is used for drying air source.

13. Pyrex pipeline: Users can easily insert sample into the Prius tube to protect the pipeline from damage.

14. Combustion boat moving system: combustion boat moves automatic to achieve more intelligent test.

15. The mode switching: mode switch (two test methods to choose from, IEC 60754-1 & IEC 60754-2).



Specification:

Product NameAcid Gas Testing Equipment Combustion Analyzer IEC 60754 for WireDimension1500mm(W)*500mm(D)*600mm(H)Power110V AC 60Hz / 230V AC 50Hz, 15AWeightabout 60kgAmbient TemperatureOperating 10ºC to 35ºC
