Fid Detector 7-Inch LCD Display Gas Chromatograph
Biobase Meihua Trading Co., Ltd.- After-sales Service：Online
- Warranty：One Year
- Appliance：The Analysis of Environmental Samples
- Ray Type：Gas Chromatograph
- Gaspath System：Double
- Detector：FID
Base Info
- Model NO.：BK-GC112A
- Certification：CE
- Spectrometer Detector：Gas Chromatograph
- Stationary Phase：Solid Adsorbent
- Mobile Phase：Gas
- Chromatography Type：Gas Chromatography
- Chromatographic Column Type：Capilary Column
- Chromatographic Column Length：10~30cm
- Chromatographic Column Diameter：0.2~0.5mm
- Oven Temp. Range：Rt~450 Degree
- Oven Temp. Program：16-Phase
- Oven Max. Temp. Heating Rate：40degree,Min
- Fid Detection Limit：<=3*10-12g,S
- Fid Baseline Drift：<=1*10-13A,30min
- Fid Linear Range：>=107
- Standard Accessory：Fid Detector, Chromatography Workstation Software
- Transport Package：Wooden or Carton
- Specification：FID detector
- Trademark：BIOBASE
- Origin：China
- Production Capacity：200units,Month
Description
Model
BK-GC112A
Oven
Temp. Range
RT+5ºC~400ºC
Temp. Accuracy
±0.02ºC
Temp. Program
9-phase/ 10 platform
Max Temp. Heating Rate
60ºC/min
Sample injector
Temp. Range
RT+7ºC~420ºC
Column or split injector can be installed.
Split mode can directly set the split ratio.
Constant pressure mode.
A separate injection system is connected.
Detector
Temp. Range
RT+7ºC~420ºC
Hydrogen Flame Ionization Detector (FID)
Logarithmic amplifier
High voltage switch control
Baseline signal display
Ignition coil control
Detection limit:≤3*10-12g/s
(Sample: n-hexadecane)
Dynamic range: 107
Thermal Conductivity Detector (TCD)
(Optional)
Bridge voltage switch control
Bridge current setting: 0-220mA
Sensitivity: 6000mv.ml/mg
Dynamic range: 105
Power Supply
AC220V±10%, 50/60Hz
Standard Accessory
FID detector, Capillary injection system, Chromatography workstation software.
Optional Accessory
TCD detector, Chromatographic column, Gas purifier.
Package Size (W*D*H)
1020*660*740mm
Gross Weight
82kg
