China Supplier Dielectric Constant (DC) and Dissipation Factor (DF) Tester
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Remote Guidance
- Warranty：2 Years
- Display：LCD
- Appliance：Transformer Oil Analysis
- Portable：Portable
- Certification：CE, ISO9001
Base Info
- Model NO.：EPOL60
- Type：Resistivity Dissipation Factor
- Capacitance：5PF~200PF
- Relative Permittivity：1.000~30.000
- Dielectric Loss Factor：0.00001~100
- DC Resistivity：2.5mohmm~20 Tohmm
- Accurancy Capacitance：+,-(1%Reading+0.5PF)
- Accurancy Relative Permittivity：+,-1% of Reading
- Accurancy Dielectric Dissipation Factor：+,-1%Reading+0.0001
- Accurancy DC Resistivity：+,-10% of Reading
- Resolution Capacitance：0.01PF
- Resolution Relative Capacitively：0.001
- Resolution Dielectric Dissipation Factor：0.00001
- Measured Temperature Range：40~120 Degree
- Temperature Measurement Error：+,-0.5 Degree
- AC Test Voltage：200~2200V Continuously Adjustable, Frequency 50Hz
- Power Consumption：100W
- Transport Package：Plywood Case
- Specification：460mm*370mm*330mm
- Trademark：EP Hipot Electric
- Origin：China
- HS Code：9030899090
- Production Capacity：1000,Year
Description
ResolutionCapacitance: 0.01pF Relative capacitively: 0.001 Dielectric dissipation factor: 0.00001 Measured temperature range: 40~120ºC Temperature measurement error: ±0.5ºC AC Test Voltage: 200~2200V Continuously adjustable, frequency 50Hz Power consumption: 100W Ambient temperature: 0ºC~40ºC Relative humidity (RH): <75% Dimensions: 460mm×370mm×330mm Total weight: 25kg
More details about Insulation Oil Dielectric Loss and DC Resistivity Tester EPOL60+, please contact EPHipot Electric, we have professional tech team to design correctly designed products and systems.
