• Model NO.：MET
• Gas Supplies：Compressed Air
• Weight of PVC Film：300g±30G,M2
• Temperature Range：700°c~1800°
• Height of Crucible：97mm
• Thickness of Iron Plate：1.5mm
• Volumn of Crucible：190ml
• Transport Package：Plywood Case
• Specification：Stainless steel
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：10 Sets,Month

Basic Info.

Model NO. MET Gas Supplies Compressed Air Weight of PVC Film 300g±30G/M2 Temperature Range 700°c~1800° Height of Crucible 97mm Thickness of Iron Plate 1.5mm Volumn of Crucible 190ml Transport Package Plywood Case Specification Stainless steel Trademark AI Origin China HS Code 9031809090 Production Capacity 10 Sets/Month

Product Description

Introduction
It is suitable to measure the resistance of protective materials to liquid metal splash.During test,certain molten metal splashes on sample which is installed at specified angel.Put a PVC film on the sample's back to contact it.Record the change of PVC film after splashing to evaluate the damage situation.According to test result,using bigger or smaller metal to repeat the test until the damage of PVC film is least.

1. Melt the metal with furnace having induction coils and high frequency generator.
2. Far IR temperature measuring device is used to control temperature and measure splashing temperature.
3. Temperature is set at 700°C~1800° by temperature controller.
4. Step motor controls inclination speed and angel.

Features
1.Imported standard PVC film, weight is 300g±30g/m2.
2.Crucible of molten metal liquid,height 97mm,diameter of upper is 80mm,diameter of bottom is 56mm,volume 190ml.
3.High frequency heating device can have melting treatment on metals,temperature is not less than 1800ºC.
4.Far IR temperature measuring device can measure temperature of molten metal liquid not less than 2400ºC,accuracy ±1%.It's also supplied with circulating water cooling device.
5.Molten metal liquid toppling device,it's angel and speed are controlled by step motor.
6.Standard stainless steel sample frame can be used to install sample and PVC film.
7.Sandbox drawer at bottom is convenient to clean test residue.
8.Outer protection cover is supplied to protect operator

Introduction of main machined parts

No.	Name	Craft
1	Contact parts of burner	Stainless steel machined as per standard
2	Auxiliary fixtures	Aluminum processing or stainless steel machined
3	Other auxiliary facilities	Thickness of iron plate is 1.5mm ,seamless welded cabinet with baking finish for cars

Main Components

No,	Name	Remark
1	Operation method	Controlled by button
2	Cylinder	Taiwan Airtac
3	High frequency heater	15KW medium frequency,with circulating water cooling
4	IR temperature measuring device	Fixed online shortwave IR temperature sensor probe transmitter,800ºC~2600ºC
5	Graphite crucible	Customized



Customer Feedback

Germany

USA

Transporation

FAQ
1.What's the delivery time?
About 2 months .

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
