3-in-1 SF6 Gas Comprehensive Analyzer Gas Dew Point Tester
HV Hipot Electric Co., Ltd.- Brand：HV HIPOT
- Customized：Customized
- Portable：Portable
- Gas：SF6
- Type：Electrochemical Gas Analyzer
- Power：220VAC ,50Hz,
Base Info
- Model NO.：GDSF-311WPD
- Use environment temperature：-20~+60 centigrade
- Environment humidity：90%RH
- Dimension：395*295*155mm
- Weight：about 2kg
- Transport Package：Export Wooden Box
- Specification：395*295*155mm
- Trademark：HV HIPOT
- Origin：China
- HS Code：9031809090
- Production Capacity：5000set,Year
Description
SF6 Humidity
Measurement method
Resistive and Capacitive measurement principle
Measurement range
dew point -80ºC--+20ºC(support ppmv)
Accuracy
±1ºC
(when the dew point temperature is below 0 ºC, the sensor output is the frost point)
Response time
63% [90%]
+20→-20ºC Td 5s[45s]
-20→-60ºC Td 10s[240s]
Resolution
0.01ºC
Repeatability
± 0.5 ºC
Display unit
ºC, ppm, ºCP20(converted value at 20ºC)
Gas flow
400-600ml/min
Flow display
0-1000mL digital flow meter
Sample gas pressure
≤1MPa
SF6 Purity
Measurement method
SF6 decomposition products
Power supply
220VAC±10%, 50Hz, AC/DC use, over-charge protection, continuous working is no lower than 8hours.
Use environment temperature
-20--+60ºC
Environment humidity
90%RH
Measurement value influence
No effect of pressure and flow
Dimension
395*295*155mm
Weight
about 2kg
