• Model NO.：TP-8017
• Trademark：TOP
• Origin：China
• HS Code：9027809900
• Production Capacity：200 Sets,Mongth

Basic Info.

Model NO. TP-8017 Trademark TOP Origin China HS Code 9027809900 Production Capacity 200 Sets/Mongth

Product Description

ASTM D323 Vapor Pressure Testing Instrument (TP-8017)



Product Application

This instrument is designed and manufactured under the requirements of standard GB/T8017 "Determination of
Petroleum Products Vapor Pressure (Reid Method)" which promulgated by The People Republic
of China, Applicable to test the vapor pressure of gasoline, volatile crude oil and other petroleum
products.


Product Features

The instrument uses floor structure, the workbench made of stainless steel, reasonable scientific
instrument design, elegant appearance, easy to operation, complete accessories.
Adopt digital temperature control, uniform bath temperature, high-precision temperature  control, fully meet the requirements of the test.
Equipped with two precision pressure gauges to detect the gas pressure inside the bomb. The accuracy
         of  gas pressure measurement up to ±0.4%.
      5. Equipped with a single opening and a double opening vapor pressure bomb, which can be placed in the
          instrument test port for synchronization test.

Technical Parameter

Power supply: AC 220V±10%, 50Hz;
Bath heating power: 1600W;
Bath temperature range: room temperature~90ºC;
Water bath temperature control accuracy: ±0.1ºC;
Pressure gauge accuracy: ±0.4%;
Ambient temperature: -10~35ºC;
Relative humidity: ≤85%;
Power consumption: less than 1700W
