Biobase China Thermal Cycler PCR Cheap Real-Time PCR Detection System
Biobase Meihua Trading Co., Ltd.- Sample Type：Liquid
- Warranty：1 Year
- Display：7 Inches Color Full Touch Screen
- Performance：Semi-automatic
- Power Supply：AC110,220V 50,60Hz
- Weight：0-50kg
Base Info
- Model NO.：BK-GR300
- Customized：Non-Customized
- Gradient Module：96,9677,384 Module
- Interface：2 USB 2.0 and LAN
- Block Temperature Range：0~105 Degree
- Max. Heating/Cooling Rate：6 Degree,S
- Transport Package：Export Standard
- Specification：362*256*255mm
- Trademark：BIOBASE
- Origin：China
- Production Capacity：500
Description
Model
BK-GR300
Gradient module
96 Module
96 wells*0.2ml
9677 Module
96 wells*0.2ml+77wells*0.5ml
384 Module
384 wells
Multi-purpose
9677 Module+In-situadapter
Display
7 inchescolortouchscreen, graphical display of protocols and running status
Communications
2 USB 2.0 and LAN
Temperature
Block Temperature Range
0ºC~105ºC
Max. Heating/Cooling Rate
6ºC/s
Temperature Uniformity
≤±0.2ºC (at 95ºC)
Temperature Accuracy
≤±0.1ºC (35ºC~100ºC)
Display Resolution
0.1ºC
Mode of Temperature Control
Sim-tube & Block mode
Gradient
Gradient Accuracy
≤±0.1ºC (35ºC~100ºC)
Column Uniformity
≤±0.2ºC (at 95ºC)
Gradient Range
30ºC~105ºC
Temp. Differential Range
1~30ºC
Gradient Capability
12 Column
Software
Max. No. of Programs
Max. 15,000 programs onboard, unlimited storage of protocols with USB flash drive
Max. Step
30steps
Max. Cycle
100 typical cycles, max. 60,000 nesting cycles
Time & Temp. Increment/Decrement
Yes, available for Long PCR & Touchdown PCR
Auto Pause / Auto Restart
Yes
Multi-userLog in
With password-based authentication prevents from view, copy and alteration of protocols
Tm Calculator
Automatically calculate the melting and annealing temperature with two primer sequences
Hold at 4ºC
Yes, aninfinite incubation time at low temperature for overnight working
Program Wizard
Yes, create PCR protocols with only a few clicks
Running Report
Yes, provide objective and precise information for the whole experiment
PC Connection
PC remote control to manage more than 120 units of A300 across the network
Heat Lid
Height of Heat Lid
Steplesslyadjustable Lid, accommodates all kinds of PCR tubes, strips and plates
Open Method
Innovative "TOP-OPEN" technology realizes open and lift in one step
Heat Lid Temperature Range
30ºC~112ºC
Auto Shut-off
Yes
Others
Power Supply
85V-265V, 50-60Hz Max. 600W
Package Size(L*W*H)
362*256*255mm
Gross Weight
10kg
