Biobase China Chromatography HPLC High Performance Liquid Chromatography
Biobase Biozone Co., Ltd.- After-sales Service：Online Support
- Warranty：1 Year
- Appliance：Medical Research
- Ray Type：,
- Gaspath System：,
- Detector：UV,Vis Detector
Base Info
- Model NO.：BK-LCI1100
- Energy Resolution：,
- Spectrometer Detector：,
- Stationary Phase：,
- Mobile Phase：,
- Chromatography Type：Liquid Chromatography
- Chromatographic Column Type：,
- Chromatographic Column Length：,
- Chromatographic Column Diameter：,
- Model：Bk-Lci1100
- Double Plunger Reciprocating Pump：1 Set
- Flow Range：0.001ml,Min-10.000ml,Min
- Setting Step Size：0.001ml,Min
- Flow Accuracy：≤±0.3% (1.00ml,Min, H2O, R.T., 8.5MPa)
- Flow Stability：Rsd≤0.1% (1.00ml,Min, H2O, R.T., 8.5MPa)
- Maximum Pressure：42MPa
- Display Pressure Error：<+-3.0%
- Pressure Fluctuation：<1.0%
- Power Dissipation：80W
- Wavelength Range：190-700nm
- Wavelength Repeatability：+-0.1nm
- Wavelength Accuracy：<+-1.0nm
- Spectrum Band Width：8nm
- Response Time：0.0s-4.9s
- Transport Package：Carton or Wooden Case
- Specification：0.001mL,min-10.000mL,min
- Origin：Shandong
- Production Capacity：1000
Description
Product Description
Product Parameters
Model
BK-LCI1100
BK-LCG1100
High Pressure Constant Flow Pump
Double plunger reciprocating pump
1 set
2 sets
Flow Range
0.001mL/min-10.000mL/min
Setting Step Size
0.001mL/min
Flow Accuracy
≤±0.3% (1.00ml/min, H2O,R.T.,8.5MPa)
Flow stability
RSD≤0.1% (1.00ml/min, H2O,R.T.,8.5MPa)
Maximum Pressure
42MPa
Display Pressure Error
≤±3.0%
Pressure Fluctuation
≤1.0%
Power Dissipation
80W
UV/VIS
Detector
Wavelength Range
190-700nm
Wavelength Repeatability
±0.1nm
Wavelength Accuracy
≤±1.0nm
Spectrum Band Width
8nm
Response Time
0.0s-4.9s
Linearity Range
1.8AU (5%)
Baseline Noise
≤±1×10-5AU
Baseline Drife
≤2.0×10-4AU/h
minimum Detectable Concentration
4.0×10-9g/mL(Naphthalene in Methanol Solution)
Detector Cell
Optical Path--10mm, Volume--10μL
Light Source
Deuterium Lamp
Power Dissipation
100W
Gradient Mixer
/
GM1100
Sampler Injector
1
Supersil ODS2 5μm ID4.6×200mm
1
Workstation (Without Computer & Printer)
1
Valve Mounting Frame
1
Kits
Isocratic System Kits
Gradient System Kits
Power Supply
AC110/220V±10%, 50/60Hz
Optional Accessory
Column Oven
