Analysis Instrument

Home > Product > Chromatography Spectroscopy Instrument

Laboratory High Performance Liquid Chromatography HPLC with UV Detector for Food Analysis

Wincom Company Ltd.
  • After-sales Service：10 Years
  • Warranty：One Year
  • Appliance：Food Analysis
  • Ray Type：γ-Ray Spectrometer
  • Gaspath System：Three
  • Detector：TCD

Base Info

  • Model NO.：LC-100PLUS
  • Energy Resolution：≤7%
  • Certification：CE, ISO, IEC, GMP
  • Spectrometer Detector：SDD
  • Stationary Phase：Liquid Solvent
  • Mobile Phase：Liquid
  • Chromatography Type：Liquid Chromatography
  • Chromatographic Column Type：Convetional Analytical Column
  • Chromatographic Column Length：10~30cm
  • Chromatographic Column Diameter：20~40mm
  • Transport Package：Carton Box
  • Specification：ONE pump
  • Trademark：NO MARK
  • Origin：China
  • Production Capacity：1000pieces,Month

Description

                          LC-100A Isocratic systemBinary gradient systemLC1620APlus
PumpSpecificationsFlow rate range0.000-10.000mL/minFlow rate accuracy≤±0.2% (1.000mL/min, 8.5MPa, water, room temperature)Flow rate precision≤0.075% (1.000mL/min,8.5MPa, water, room temperature)Pressure range≤42MPaPressure fluctuation≤1%LC1620APlus
UV DetectorSpecificationsWavelength range190-700nmBaseline noise≤±0.5×10-5AUBaseline drift≤1×10-4AU/h Detection Limit4×10-9 g/ml(Naphthalene/methyl alcohol solvent)Wavelength accuracy±1nmLinearity range1.8AU (5%)
