• Model NO.：GDY-1C
• Temperature Resolution：0.0001c
• Rsd(Relative Standard Deviation)：No More Than 0.1%
• Test Period：No More Than 13mins
• Measuring Range：5mj,Kg~40mj,Kg
• Pressure Endurance of Oxygen Bomb：20 MPa
• Net Weight：55kg
• Transport Package：Packed in Veneer Case
• Specification：69*55*48; 45*37*25; 58*52*84
• Trademark：GOLD
• Origin：Chongqing, China
• HS Code：9031809090
• Production Capacity：100 Sets, Month

Basic Info.

Model NO. GDY-1C Temperature Resolution 0.0001c Rsd(Relative Standard Deviation) No More Than 0.1% Test Period No More Than 13mins Measuring Range 5mj/Kg~40mj/Kg Pressure Endurance of Oxygen Bomb 20 MPa Net Weight 55kg Transport Package Packed in Veneer Case Specification 69*55*48; 45*37*25; 58*52*84 Trademark GOLD Origin Chongqing, China HS Code 9031809090 Production Capacity 100 Sets/ Month

Product Description

Automatic Oxygen Bomb Calorimeter for Coal



Introduction:

The Automatic Oxygen Bomb Calorimeter is designed and made as per the National Standard of People's Republic of China GB/T213-2008 and ASTM D240 Test Method for Calorific Value of coal, GB/T384-1988 Test Method for Calorific Value of Petroleum Products and Calibration Regulation of People's Republic of China JJG672-2001 Oxygen Bomb Calorimeter, as well as Shanghai enterprise standard Q/YXYY 10 GDY Series Oxygen Bomb Calorimeter.


Features:

1. The bomb calorimeter adopts semiconductor refrigeration to decide the refrigerating capacity according to the calorific value, the instrument can automatically adjust water temperature and keep water in a relative constant temperature range, realize the continuously and long time test requirement, and make sure the test result is correct.
2. The bomb calorimeter adopts USB port,convenient to connect. One computer can control many sets of Oxygen Bomb Calorimeter.
3. With a electronic measuring cup itself, no need to weigh the water by manual, it can measure the water volume automatically, the repetitive error<0.4g
4. Automatically detecting the resistance of ignition filament, automatically checking the installing condition of ignition filament before test.
5. Standard pipeline design, vastly shortening the pipeline,and more reasonable pipeline design to ensure more precision of test results.
6. Adopting professional discharge water ports,more convenient and fast when the  instrument drains away water or change the water.
7. The electronic balance with communication function to share the data by the internet.


Specifications:


1	Measuring temperature range	5ºC~40ºC
2	Temperature resolution	0.0001ºC
3	RSD(Relative standard deviation)	≤0.1%
4	Test period	≤13mins
5	Measuring range	5MJ/kg~40MJ/kg
6	Accuracy	Better than GB/T213-2008 The determination method of coal calorific value
7	Pressure endurance of oxygen bomb	20 MPa
8	Relative humidity	≤85%
9	Power supply	AC 220V±10V, 50 Hz
10	Total power consumption	≤0.2kW
11	Outline dimension	540mm*420mm*420mm
12	Net weight	55kg

Picture of Automatic Oxygen Bomb Calorimeter:
