SF6 Gas Infrared Imaging Leak Detector
HV Hipot Electric Co., Ltd.- Brand：HV Hipot
- Customized：Customized
- Portable：Portable
- Gas：SF6
- Type：Infrared Absorption Analyzer
- Detector Type：Uncooled vanadium oxide focal plane
Base Info
- Model NO.：GDIR-1000L
- Resolution：320*240
- Total pixels：76800
- Power supply：DC 7.2V
- Lens：50mm F,1
- Transport Package：Standard Export Woden Box
- Trademark：HV Hipot
- Origin：Wuhan, China
- HS Code：9030899090
- Production Capacity：5000set,Year
Description
Basic Info.
Model NO. GDIR-1000L Resolution 320*240 Total pixels 76800 Power supply DC 7.2V Lens 50mm F/1 Transport Package Standard Export Woden Box Trademark HV Hipot Origin Wuhan, China HS Code 9030899090 Production Capacity 5000set/YearProduct Description
Portable SF6 Gas Infrared Imaging Leak Detector GDIR-1000LProduct Description
GDIR-1000L SF6 Gas Infrared Imaging Leak Detector is a highly technical instrument which is independently developed by our company and has independent intellectual property rights. It is specially used to directly observe the leakage of SF6 gas equipment in the operation of the electric power industry. Adopts infrared imaging principle and unique image processing algorithm, to ensure test sensitivity and reducibility of the instrument. Simple and reliable operation, high test sensitivity, the image is intuitionistic and clear, able to find the SF6 gas leakage point of the electrical equipment accurately and quickly.
Features
- Infrared imaging detection, visualization;
- Fast Start-up, no need to warm up, and 10 seconds can be put into detection;
- No need for active infrared light source enhancement, wide test interface;
- SF6 gas leak points can be observed on the detector imaging surface;
- Non-contact detection mode to ensure the personal safety of field workers;
Specifications
| Detector Type | Uncooled vanadium oxide focal plane |
| Spectrum band | 10.3µm-10.7µm |
| Frame rate | 25Hz |
| Resolution | 320*240 |
| Total pixels | 76800 |
| Thermal Sensitivity | <15 mK @ +30°C (+86°F) |
| NETD | 40mk(F/1) |
| Lens | 50mm F/1 |
| Measurement sensitivity | 0.001mL/s |
| Power consumption | ≤5W@25ºC |
| Power supply | DC 7.2V |
| Battery working time | ≥5 hours |
| Start-up time | 10s |
| Storage & videotape | Solid state hard disk |
| Video output | Digital video output |
| Communication mode | USB interface |
| Working temperature | -40ºC ~ +50ºC |
| Storage temperature | -55ºC ~ +70ºC |
| Weight | 3 kg (including battery) |
| Software | Analysis and report |
| Zoom | 1 - 8× continuous digital |
| Focus | Auto & Manual |
| Color LCD | 7" |
| Adjustable Viewfinder | Tiltable OLED, 1080P |
| Video Camera w/Lamp | 3.2 MP |
| Laser Spot | Yes |
| Delta T | Yes |
