• Model NO.：SC80
• Transport Package：Delivery Package: Carton
• Specification：CE, SGS
• Trademark：SADT
• Origin：China
• HS Code：90318090
• Production Capacity：500 Pieces,Month

Basic Info.

Model NO. SC80 Transport Package Delivery Package: Carton Specification CE, SGS Trademark SADT Origin China HS Code 90318090 Production Capacity 500 Pieces/Month

Product Description

Precise Color Reader SC80 Details:

SC80 precise color reader is mainly applied to plastic, painting, design, plating, costume, printing and dyeing industries.
It can do the color analysis and color controlling.


KEY FEATURES:

The 2.4" color ful screen and por table design make you feel comfor table.
Suitable for internal, external color evaluation and data control.
High precision measurement, stable per formance.
PC sof tware for data management.
National measurement accreditation.
USB data transmit
Yellow, whiteness measurement

Model	SC80
Accuracy	0.08 (average value of 30 times @ the standard white tabula)
Lighting/Inspecting system	8/d (8o falloff/diffuse reflection)   SCI (include flat mirror light)
Light source	White light source , halogen lamp
Inspection angle	10 degree angle of view in CIE
Measuring conditions	D65
Rectification	White board rectification/Black board rectification
Storage	100 samples and 100 data groups for each sample
Display	L*a*b*, L*c*h*, ΔE*ab, XYZ, with respect to RGB, Δ(L*a*b*), Δ(L*C*H*)   Whiteness: Hunter Whiteness, Ganz Whiteness   Yellowness: Yellowness index
Communication interface	USB2.0, printer(optional)
Aperture (mm)	Ø8
Power supply	4 pcs of AA alkaline batteries or nickel batteries special adaptor (DC, 5V)
Weight (g)	550
Dimension (mm)	77x86x210
