• Model NO.：TP-1500
• Transport Package：Wooden Case
• Specification：CE,ISO
• Trademark：TOP
• Origin：China
• HS Code：9025800000
• Production Capacity：200 Sets,Month

Basic Info.

Model NO. TP-1500 Transport Package Wooden Case Specification CE/ISO Trademark TOP Origin China HS Code 9025800000 Production Capacity 200 Sets/Month

Product Description

Portable Chilled Mirror Dew Point Test equipment TP-1500




Applications:
TP-1500 type dew point meter is a truly portable instrument. It uses rechargeable batteries and is durable, lightweight and easy to carry. It is designed specifically for use in the field, with features of high precision, wide range, low price. It is suitable for the fields of electricity, steel, petrochemical, natural gas, drying oven, pharmaceutical oven, environmental testing, calibration laboratories, spray booth, process gas monitoring and gas production.







Features: 1. Wide range of 1.1-60 ~ + 75 ºC 2. Chilled mirror measurement principle, high accuracy and reliability 3. Sensors and instrumentation are separable 4. ABC self-balancing and mirror automatic detection system contamination 5. The analog current or voltage signal output 6. Dual alarm output Technical parameters: 1. Dew point range: single stage cooling (S1 sensor): - 20 ~ 50 ºC; two-stage cooling(S2 sensor): - 30 ~ 50 ºC; three-stage cooling (S3 sensor): - 70 ~ 50 ºC (S3 type sensor 220VAC power supply) 2. Accuracy: +/- 0.25 ºC 3. Operating temperature: 0 ~ 50 ºC 4. Connection size: 1/4 "card sets 5. Sampling rate: 0.5 ~ 5 SCFH (instrument's flow meter) 6. Sample pressure: 0 ~ 150 psig (higher pressures can be customized) 7. Output signals: analog output: 4 ~ 20mA (or 0 ~ 5VDC) 8. Display: red LED display, 0.5  high: 8 Display 9. Alarm: sound alarm; displaying the word "ALARM" 10. Dimensions: height:14.75; length: 18; width: 7 11. Weight: 11 kg 12. Carrying case: with a waterproof / anti-corrosion carrying case



Our oil filtration machine:   Series ZY Single-Stage Vacuum Transformer Oil Purifier Series ZYD Double High Vacuum Transformer Oil Purifier Series ZYB Multiply-Function insulating oil treatment machine Series TY Turbine Oil Purification Apparatus Series TYA Lubricating oil/ hydraulic oil purification unit Series TYB Portable light Fuel oil purification machine Series TYD Vacuum dehydrator Series TYF Phosphate ester fire-resistance oil purifier Series PL Plate pressure oil purifier Series TYD Vacuum dehydrator Series EFD Explosion protection filtration machine Series BAM Press filtration system Series ZKCC Vacuum pumping device Series COP Cooking oil purification machine Series CYS Centrifugal oil purification machine Series JL Portable oil filtering and oiling machine   Our oil tester/ analyzer: Series IIJ-II Insulating oil breakdown strength tester(oil BDV tester) Series HTJS-H Insulating oil dielectric tester (dielectric loss tester for insulating oil) Series HTJS-V Tan-Delta Tester (anti-jamming dielectric loss tester for HV electrical equipment) Series TP-3A Water content tester/ moisture sensor Series TPV-8 Viscosity analyzer Series TPC-2100 Flash point analyzer (close cup) Series TPO-2100 Flash point analyzer (open cup) Series CL-3 Interfacial tension analyzer
